Onkyo DV-S757 Service Manual

DV-S757
DV-S757
EXPLODED VIEW PARTS LIST-2
NOTE: THE COMPONENTS IDENTIFIED BY MARK ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE ONLY WITH PART NUMBER SPECIFIED.
NOTE:
<MUP> :European arer(Regional restriction code-2)
<MUT> :Some Asian arer(Regional restriction code-3)
<MUS> :South American arer(Regional restriction code-4)
<MUR> :Chinese arer(Regional restriction code-6)
<B> :Black color model only
<G> :Golden color model only
<S> :Silver color model only
Z10
24150022 DB-VPB302, Main PC board ass'y
Z11
24801010 DB-VLD301-006, DVD mechanism ass'y
Z12
24840149A DB-VAC301, adapter(L)
Z13
24840150A DB-VAC302, adapter(R)
U1
1H465515-1B NADIS-7215-1B, Display PC board ass'y <MUP>
1H465515-1C NADIS-7215-1C, Display PC board ass'y <MUT>
1H465515-1D NADIS-7215-1D, Display PC board ass'y <MUS>
1H465515-1E NADIS-7215-1E, Display PC board ass'y <MUR>
U2
1H465516-1B NADIS-7216-1B, Control switch PC board ass'y <MUP>
1H465516-1C NADIS-7216-1C, Control switch PC board ass'y <MUT>
1H465516-1D NADIS-7216-1D, Control switch PC board ass'y <MUS>
1H465516-1E NADIS-7216-1E, Control switch PC board ass'y <MUR>
U3
1H465517-1B NAVD-7217-1B, AV connector PC board ass'y <MUP>
U4
1H465518-1C NASW-7218-1C, Power switch PC board ass'y <MUT>
1H465518-1D NASW-7218-1D, Power switch PC board ass'y <MUS>
1H465518-1E NASW-7218-1E, Power switch PC board ass'y <MUR>
U5
1H465519-1B NAPS-7219-1B, AC inlet PC board ass'y
U8
1H465515-1B NAETC-7222-1B, Holder PC board ass'y
U9 1H465524-1B NAAR-7224-1B, Output terminal PC board ass'y <MUP>
1H465524-1C NAAR-7224-1C, Output terminal PC board ass'y <MUS,MUT,MUR>
U10 1H465525-1B NAETC-7225-1B, Phones jack PC board ass'y <MUP>
1H465525-1C NAETC-7225-1C, Phones jack PC board ass'y <MUS,MUT,MUR>
U11
24150021A
NGPS-0021-100V-240V, Power supply unit <MUP, MUT, MUS, MUR>
61
27122897B Rear panel <MUP>
27122898B Rear panel <MUT>
27122899B Rear panel <MUS>
27122900B Rear panel <MUR>
E250
2047201512 NCFC7-201512, Flexible flat cable <MUP>
E701
2045222012 NCFC5-222012, Flexible flat cable
E705
2009990702UL NSAS-10P0978
E903
260208 Binder, UL
F1
252073 or 1.6A-SE-EAK IECFUSE
252273 1.6A-SE-TL250V
S731
25035710 NPS-115-S673, Cursor switch ass'y
REF.NO. PART NO. DESCRIPTION
REF.NO. PART NO. DESCRIPTION
