DV-SP301

BLOCK DIAGRAM

DISPLAY CIRCUIT

From Power supply unit

To Output Terminal

To Main circuit

IC91

IC-DISPLAY uPD16311GC-AB6 HIGH VOLTAGE DRIVER

FL91

VFD_012BT159GNK

RM91

38KHz
