PRINTED CIRCUIT BOARD PARTS LIS
OUTPUT TERMINAL PC BOAR
!: Sa
ety par
CIRCUIT NO. PART NO. DESCRIPTION
ICs
Output PC IC82 55128990 OPERAMP BA4560F DUAL OP
Output PC IC83 55164460 OPERAMP NJM4556AM DUAL OP
Output PC IC84 55164740 D-LEM GP1F32T RD RND CL
Output PC IC85 55491690 REGPOSFXD KIA7805AP NORMAL
Output PC IC85 55505580 REGPOSFXD KA7805 TO-220 NORMAL
Output PC IC86 55164460 OPERAMP NJM4556AM DUAL OP
Output PC IC87 55164460 OPERAMP NJM4556AM DUAL OP
Output PC IC88 55420450 VIDEO PROC MM1568AJBE SSOP34A AMPLIFIER&DRIVER
Transistors
Output PC Q801 20970460 KTC3875Y N 50V 150MI0A
Output PC Q802 20970480 KTA1504Y P -50V -150MI0A
Output PC Q803 55039430 DTC323TK N 2K2 OHM
Output PC Q804 55133190 DTA114YKA P 10K0 OHM 47K0 OHM
Output PC Q805 55133180 DTC114YKA N 10K0 OHM 47K0 OHM
Output PC Q806 20970460 KTC3875Y N 50V 150MI0A
Output PC Q811 55039430 DTC323TK N 2K2 OHM
Diodes
Output PC D801 20496510 1SS355 35.0V 225MI0A
Output PC D803 20496510 1SS355 35.0V 225MI0A
Output PC D804 70436540 1N4148 100.0V 150E-3A
Output PC D810 55177710 ZENER UDZS 5.1 B 5.1V 200MI0W
Output PC D811 55177710 ZENER UDZS 5.1 B 5.1V 200MI0W
Output PC D812 55177710 ZENER UDZS 5.1 B 5.1V 200MI0W
Output PC D813 55177710 ZENER UDZS 5.1 B 5.1V 200MI0W
Output PC D814 55177710 ZENER UDZS 5.1 B 5.1V 200MI0W
Output PC D815 55177710 ZENER UDZS 5.1 B 5.1V 200MI0W
Output PC D816 55177710 ZENER UDZS 5.1 B 5.1V 200MI0W
Output PC D817 55177710 ZENER UDZS 5.1 B 5.1V 200MI0W
Output PC D818 55177710 ZENER UDZS 5.1 B 5.1V 200MI0W
Output PC D819 55177710 ZENER UDZS 5.1 B 5.1V 200MI0W
Output PC D820 55177710 ZENER UDZS 5.1 B 5.1V 200MI0W
Output PC D821 55177710 ZENER UDZS 5.1 B 5.1V 200MI0W
Socket AS
Output PC CN81 55687570 10P 60MM UL1007 PVC DISCRETE 26 12
Socket
Output PC CP82 55179440 CONN 1.25MM 27 FE ST WH GF120-27S-TS 2794 A4
Output PC CP83 55090070 CONN 2.0MM 2 MA ST NAT LW2002P0200T 0 0
Pin Jack
Output PC JK81 55164750 CON PHONO SCKT W/GN 1 PINS
Output PC JK82 55175260 CON PHONO SCKT RCA 2P W/GND CAP JE020059PN
Output PC JK83 55191220 CON DIN SCKT MIX SOCKET RCA & S-VIDEO
Output PC JK84 55149420 CON PHONO SCKT RCA-314P RBG
Output PC JK85 55739620 CON PHONO SCKT EST-J35228 2 PINS
Capacitors
Output PC C801 20251250 Film. 47N0F +10% -10% 50.0V X7R
Output PC C803 20251250 Film. 47N0F +10% -10% 50.0V X7R
Output PC C804 11058670 Film. 100P0F +5% -5% 50.0V NP0
Output PC C805 30939240 Film. 22N0F +10% -10% 50.0V X7R
Output PC C806 30939240 Film. 22N0F +10% -10% 50.0V X7R
Output PC C811 20267830 Elect. C 47U0F +20% 16.0V 85C 20251640
Output PC C812 50882800 Film. 1N5F +10% -10% 50.0V X7R
Output PC C813 20468970 Film. 330P0F +5% -5% 50.0V NP0
Output PC C814 20267830 Elect. C 47U0F +20% 16.0V 85C 20251640
Output PC C815 50882800 Film. 1N5F +10% -10% 50.0V X7R
Output PC C816 20267830 Elect. C 47U0F +20% 16.0V 85C 20251640
Output PC C817 11058670 Film. 100P0F +5% -5% 50.0V NP0
Output PC C818 80436820 Film. 680P0F +10% -10% 50.0V X7R
Output PC C819 20267830 Elect. C 47U0F +20% 16.0V 85C 20251640
To Next Page
