Output PC C820 20268840 Elect. C 1U0F +20% 50.0V 85C
Output PC C825 20268180 Elect. C 330U0F +20% 16.0V 85C
Output PC C827 11059320 Film. 1N0F +10% -10% 50.0V X7R
Output PC C829 20468970 Film. 330P0F +5% -5% 50.0V NP0
Output PC C830 11058670 Film. 100P0F +5% -5% 50.0V NP0
Output PC C831 50882800 Film. 1N5F +10% -10% 50.0V X7R
Output PC C832 20267830 Elect. C 47U0F +20% 16.0V 85C 20251640
Output PC C834 20267830 Elect. C 47U0F +20% 16.0V 85C 20251640
Output PC C835 20267830 Elect. C 47U0F +20% 16.0V 85C 20251640
Output PC C836 20269080 Elect. C 220U0F +20% 10.0V 85C
Output PC C837 11058670 Film. 100P0F +5% -5% 50.0V NP0
Output PC C838 80436820 Film. 680P0F +10% -10% 50.0V X7R
Output PC C839 50882800 Film. 1N5F +10% -10% 50.0V X7R
Output PC C840 11059320 Film. 1N0F +10% -10% 50.0V X7R
Output PC C841 20267830 Elect. C 47U0F +20% 16.0V 85C 20251640
Output PC C842 11058670 Film. 100P0F +5% -5% 50.0V NP0
Output PC C845 20267290 Film. 100N0F +80% -20% 50.0V Y5V
Output PC C846 20269020 Elect. C 100U0F +20% 16.0V 85C
Output PC C847 11059320 Film. 1N0F +10% -10% 50.0V X7R
Output PC C848 20267290 Film. 100N0F +80% -20% 50.0V Y5V
Output PC C849 11059340 Film. 10N0F +10% -10% 50.0V X7R
Output PC C850 20267290 Film. 100N0F +80% -20% 50.0V Y5V
Output PC C851 20267290 Film. 100N0F +80% -20% 50.0V Y5V
Output PC C852 20251930 Elect. C 22U0F +20% 16.0V 85C
Output PC C853 20267290 Film. 100N0F +80% -20% 50.0V Y5V
Output PC C854 20268840 Elect. C 1U0F +20% 50.0V 85C
Output PC C855 20268840 Elect. C 1U0F +20% 50.0V 85C
Output PC C856 20267290 Film. 100N0F +80% -20% 50.0V Y5V
Output PC C857 20269020 Elect. C 100U0F +20% 16.0V 85C
Output PC C858 20251930 Elect. C 22U0F +20% 16.0V 85C
Output PC C859 20269020 Elect. C 100U0F +20% 16.0V 85C
Output PC C860 20251930 Elect. C 22U0F +20% 16.0V 85C
Output PC C861 20269020 Elect. C 100U0F +20% 16.0V 85C
Output PC C862 20251930 Elect. C 22U0F +20% 16.0V 85C
Output PC C863 20269020 Elect. C 100U0F +20% 16.0V 85C
Output PC C864 20251930 Elect. C 22U0F +20% 16.0V 85C
Output PC C865 20269020 Elect. C 100U0F +20% 16.0V 85C
Output PC C866 20251930 Elect. C 22U0F +20% 16.0V 85C
Output PC C867 11059440 Film. 10P0F +0P25F -0P25F 50.0V NP0
DISPLAY CIRCUIT PC BOAR
D
CIRCUIT NO. PART NO. DESCRIPTION
ICs
Display PC IC91 20920150 UPD16311GC-AB6 HIGH VOLTAGE DRIVER
Display PC IC91 55009420 PT6311 VFD DRIVER
Display PC RM91 55193920
N
JL64H380A RECEIVER 38KHZ
Transistor
Display PC Q701 55133180 DTC114YKA N 10K0 OHM 47K0 OHM
Diodes
Display PC D901 70436540 1N4148 100.0V 150E-3A
Display PC D902 70436540 1N4148 100.0V 150E-3A
Display PC D904 70436540 1N4148 100.0V 150E-3A
Display PC D905 20415060 1N4004 400.0V 1.0A
Display PC LD91 55125510 D-LEM LTL-1CHE RD RND 3.0 DIFU 5.6CD
Socket AS
Display PC CN92 55212780 WIRE CON ASY UNIQUE 7P 60MM UL1007 PVC DISCRETE 26
Display PC CN93 55158680 WIRE CON ASY UNIQUE 2 80MM UL1007 PVC DISCRETE 26
Display PC CN91 55543550 WIRE CON ASY 05235F 5P 230MM UL1007 PVC DISCRETE 26 1
Socket
Display PC CP91 55078520 CONN 2.0MM 2 MA R NAT LW2003P02 0 0
FL Display
