Display PC FL91 55684080 DISPLAY 12-BT-159GNK
Holder
Display PC 0050 55678240 MLD HOLDER VFD DV-SP301
Capacitors
Display PC C901 11059320 Film C 1N0F +10% -10% 50.0V X7R
Display PC C902 20251250 Film C 47N0F +10% -10% 50.0V X7R
Display PC C903 20267710 Elect. C 10U0F +20% 16.0V 85C 20251630
Display PC C904 20267290 Film C 100N0F +80% -20% 50.0V Y5V
Display PC C905 20267290 Film C 100N0F +80% -20% 50.0V Y5V
Display PC C916 30938700 Film C 68P0F +5% -5% 50.0V NP0
Display PC C917 30938700 Film C 68P0F +5% -5% 50.0V NP0
Display PC C918 30938700 Film C 68P0F +5% -5% 50.0V NP0
Display PC C919 30938700 Film C 68P0F +5% -5% 50.0V NP0
Display PC C920 30938700 Film C 68P0F +5% -5% 50.0V NP0
Display PC C921 30938700 Film C 68P0F +5% -5% 50.0V NP0
Display PC C922 30938700 Film C 68P0F +5% -5% 50.0V NP0
Display PC C923 30938700 Film C 68P0F +5% -5% 50.0V NP0
Display PC C924 30938700 Film C 68P0F +5% -5% 50.0V NP0
Display PC C925 30938700 Film C 68P0F +5% -5% 50.0V NP0
Display PC C926 30938700 Film C 68P0F +5% -5% 50.0V NP0
Display PC C927 30938700 Film C 68P0F +5% -5% 50.0V NP0
Tact Switches
Display PC SW91 55145270 SWI TACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
Display PC SW92 55145270 SWI TACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
Display PC SW93 55145270 SWI TACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
Display PC SW94 55145270 SWI TACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
Display PC SW95 55145270 SWI TACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
Display PC SW96 55145270 SWI TACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
Display PC SW97 55145270 SWI TACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
Display PC SW98 55145270 SWI TACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
Resistors
Display PC R912 55261210 RCF 15R0 OHM +5% 250MI0W
Display PC R913 55261210 RCF 15R0 OHM +5% 250MI0W
Display PC R914 55261210 RCF 15R0 OHM +5% 250MI0W
Display PC R915 55261210 RCF 15R0 OHM +5% 250MI0W
Display PC R916 30939360 RCF 10R0 OHM +5% 250MI0W
Display PC R917 11066420 RMGCFMIN 390R0 OHM +5% 100MI0W
Display PC R918 80440510 RMGCFMIN 0 OHM +0% 100MI0W
Display PC R919 80440510 RMGCFMIN 0 OHM +0% 100MI0W
Finger
Display PC FG91 55209110 PIN-STRIP 0.0MM 1
MAIN CIRCUIT PC BOAR
D
CIRCUIT NO. PART NO. DESCRIPTION
ICs
Main PC IC21 5568753A STM5589 PQFP208 MPEG VIDEO DECODER
Main PC IC22 20940740 EEPROM M24C02WMN6
Main PC IC23 55116380 FAN8082 MOTOR DRIVER
Main PC IC24 55421050 BA18BC0FP TO252-3 LOW VOLTAGE DROP
Main PC IC31 55156290 IC-DRAM 100M0 HZ 8N0 64M(1M*16*4) HY57V651620BTC-8 125M
Main PC IC41 5552334A MEMORY FLASH M29W160ET70N6
Main PC IC51 55133310 M74HCU04M1R INVERTER HCT
Main PC IC61 55291470 IC-CONV WM8728 D/A
Transistors
Main PC Q201 20970460 KTC3875Y N 50V 150MI0A
Main PC Q202 20970460 KTC3875Y N 50V 150MI0A
Main PC Q203 20970460 KTC3875Y N 50V 150MI0A
Main PC Q204 20970480 KTA1504Y P -50V -150MI0A
Main PC Q206 55133180 DTC114YKA N 10K0 OHM 47K0 OHM
Main PC Q207 55133190 DTA114YKA P 10K0 OHM 47K0 OHM
Coils
