Main PC L201 55188040 LF-SMD 2U2H +10%
Main PC L202 55188040 LF-SMD 2U2H +10%
Main PC L203 55188040 LF-SMD 2U2H +10%
Main PC L204 55126670 F BEAD SURFACE MT 1000OHM FCM2012H-102T04
Main PC L205 55126670 F BEAD SURFACE MT 1000OHM FCM2012H-102T04
Main PC L206 55126670 F BEAD SURFACE MT 1000OHM FCM2012H-102T04
Main PC L207 55185100 LF-SMD 22U0H +10%
Main PC L208 55188040 LF-SMD 2U2H +10%
Main PC L209 55188040 LF-SMD 2U2H +10%
Main PC L211 10328750 RMGCFMIC 0 OHM +0% 62MI5W
Main PC L301 55188040 LF-SMD 2U2H +10%
Main PC L501 55126670 F BEAD SURFACE MT 1000OHM FCM2012H-102T04
Main PC L601 10328750 RMGCFMIC 0 OHM +0% 62MI5W
Main PC L602 10328750 RMGCFMIC 0 OHM +0% 62MI5W
Diodes
Main PC D201 20414280 D-ZENER 1N5232B 5.6V 500MI0W
Main PC D202 55165360 D-SLP RB441Q-40 40.0V 100MI0A
Main PC D203 70436540 D-SLP 1N4148 100.0V 150E-3A
Main PC D204 70436540 D-SLP 1N4148 100.0V 150E-3A
Socket AS
Main PC CN25 55420050 2P 250MM UL1533 SHIELD 26 1
Sockets
Main PC CP21 55124600 1.25MM 19 FE ST WH GF120-19S-TS 2794 A6
Main PC CP22 55125910 1.0MM 15 FE ST BK 00-6232-015-006-800 0 0
Main PC CP23 55125910 1.0MM 15 FE ST BK 00-6232-015-006-800 0 0
Main PC CP24 55179440 1.25MM 27 FE ST WH GF120-27S-TS 2794 A4
Main PC CP27 55090060 2.0MM 7 MA ST NAT LW2002P07 0 0
Main PC CP28 55164790 2.5MM 02 MA ST BK 1649 C2
Capacitors
Main PC C201 20267290 Film C 100N0F +80% -20% 50.0V Y5V
Main PC C202 20267290 Film C 100N0F +80% -20% 50.0V Y5V
Main PC C203 11059340 Film C 10N0F +10% -10% 50.0V X7R
Main PC C204 20268940 Elect. C 100U0F +20% 10.0V 85C
Main PC C205 11059340 Film C 10N0F +10% -10% 50.0V X7R
Main PC C206 20268940 Elect. C 100U0F +20% 10.0V 85C
Main PC C207 20267290 Film C 100N0F +80% -20% 50.0V Y5V
Main PC C208 20267290 Film C 100N0F +80% -20% 50.0V Y5V
Main PC C209 11059340 Film C 10N0F +10% -10% 50.0V X7R
Main PC C210 20268940 Elect. C 100U0F +20% 10.0V 85C
Main PC C211 11059440 Film C 10P0F +0P25F -0P25F 50.0V NP0
Main PC C212 11059440 Film C 10P0F +0P25F -0P25F 50.0V NP0
Main PC C213 11059440 Film C 10P0F +0P25F -0P25F 50.0V NP0
Main PC C214 11059440 Film C 10P0F +0P25F -0P25F 50.0V NP0
Main PC C215 20288040 CCCFMIC 100N0F +80% -20% 16.0V Y5V
Main PC C216 30938740 Film C 470P0F +5% -5% 50.0V NP0
Main PC C217 20267290 Film C 100N0F +80% -20% 50.0V Y5V
Main PC C218 20288040 CCCFMIC 100N0F +80% -20% 16.0V Y5V
Main PC C219 20267290 Film C 100N0F +80% -20% 50.0V Y5V
Main PC C220 11059340 Film C 10N0F +10% -10% 50.0V X7R
Main PC C221 20268940 Elect. C 100U0F +20% 10.0V 85C
Main PC C222 20267290 Film C 100N0F +80% -20% 50.0V Y5V
Main PC C223 20267290 Film C 100N0F +80% -20% 50.0V Y5V
Main PC C224 20267290 Film C 100N0F +80% -20% 50.0V Y5V
Main PC C225 20288040 CCCFMIC 100N0F +80% -20% 16.0V Y5V
Main PC C226 10137340 CCCFMIC 68P0F +10% -10% 50.0V NP0
Main PC C227 10137340 CCCFMIC 68P0F +10% -10% 50.0V NP0
Main PC C228 20267830 Elect. C 47U0F +20% 16.0V 85C 20251640
Main PC C229 20268620 Elect. C 470U0F +20% 6.3V 85C
Main PC C230 20267830 Elect. C 47U0F +20% 16.0V 85C 20251640
Main PC C231 20268940 Elect. C 100U0F +20% 10.0V 85C
Main PC C232 20268940 Elect. C 100U0F +20% 10.0V 85C
Main PC C233 20268620 Elect. C 470U0F +20% 6.3V 85C
Main PC C234 20288040 CCCFMIC 100N0F +80% -20% 16.0V Y5V
