1. Connection from GND terminal
of U2 to the Ground line as seen
is added in the schematic. No
change in hardware is needed.
2. R24 value is 2.2K ohm.
Model: DV-SP301
03/01/2004
1
2
Ref#SP301-030204Subject: Correction of service manual.
DV-SP301 Service Manual Correction
