IC88: MM1568AJBE VIDEOPROC AMPLIFIER&DRIVER
1 VCC1 VCC -
2 CIN CROMA INPUT I
3 MUTE1 MUTE SELECT(USING OF MUTE AND POWER-SAVING) -
4 VIN VIDEO INPUT COMPOSITE(INPUT CLAMP:SYNC TIP) I
5 YC MIX YC MIX -
6 YIN VIDEO INPUT LUMINANCE(INPUT CLAMP:SYNC TIP) I
7 BIAS BIAS -
8 GND1 GROUND -
9NCNC -
10 GND1 GROUND -
11 NC NC -
12 CYIN LUMINANCE INPUT(THE INPUT CAN SELECT SYNC TIP CLAMP OR BIAS) I
13 CLP INPUT CLAMP SELECT I
14 CbIN COMPONENT INPUT I
15 MUTE2 MUTE SELECT(USING OF MUTE AND POWER-SAVING) -
16 CrIN COMPONENT INPUT I
17 GND2 GROUND -
18 CrOUT SIGNAL OUT O
19 CrSAG SAG CORRECTION O
20 GND2 GROUND -
21 CbOUT SIGNAL OUT O
22 CbSAG SAG CORRECTION O
23 GND2 GROUND -
24 CYOUT SIGNAL OUT O
25 CYSAG SAG CORRECTION O
26 GND2 GROUND -
27 YOUT SIGNAL OUT O
28 YSAG SAG CORRECTION O
29 GND2 GROUND -
30 VOUT SIGNAL OUT O
31 VSAG SAG CORRECTION O
32 GND2 GROUND -
33 COUT CROMA OUTPUT O
34 VCC2 VCC -
PIN NAME MAIN FUNCTION
PIN
NUMBER
I/O
DV-SP301
IC TERMINAL DESCRIPTION
