DV-SP301
IC TERMINAL DESCRIPTION
Pin
number
Pin name Main function
Alternate function
Pin
type
Input Output
Left Side
1 PIO2[5] PIO2[5] SC1_CMD_VCC
AUD_DEBUG_OUT
SSC1_MTSRout
I/O
2 PIO2[6] PIO2[6] SC1_DATA_DIR
DAC_PCMOUT3
(VCR)
I/O
3 PIO2[7] PIO2[7] SC1_DETECT
AUD_DEBUG_IN
YC_CLKOUT I/O
4 VDD3_3 3.3 V power supply Power
5 VSS Ground Power
6 PIO3[0] PIO3[0] MAFEIF_SCLK
PARA_DATA{0]
I2S_DATA_OUT I/O
7 PIO3[1] PIO3[1] MAFEIF_DIN
PARA_DATA[1]
I2S_BCLK_OUT I/O
8 PIO3[2] PIO3[2] MAFEIF_FSI
PARA_DATA[2]
I2S_BFLAG_OUT I/O
9 PIO3[3] PIO3[3] CAPTURE_IN0
PARA_DATA[3]
I/O
10 PIO3[4] PIO3[4] CAPTURE_IN1
PARA_DATA[4]
UART1 RTS (RTS1) I/O
11 PIO3[5] PIO3[5] CAPTURE_IN2
PARA_DATA[5]
UART2 RTS (RTS2) I/O
12 PIO3[6] PIO3[6] PARA_DATA[6]
UART1 CTS (CTS1)
COMP_OUT1 I/O
13 PIO3[7] PIO3[7] PARA_DATA[7]
UART2 CTS (CTS2)
COMP_OUT0 I/O
14 VDD1_8 1.8V power supply Power
15 VSS Ground Power
16 B_DATA
I
2
S data
SER_DATA
RS_DATA
I
17 B_BCLK
I
2
S bit clock
SER_BCLK
RS_BCLK
I
18 B_FLAG
I
2
S error flag DVD
SER_VALID
RS_DVALID
I
19 B_SYNC
I
2
S sector/ABS time
SER_
SYNC
The table column
A/ternate function
shows the secondary use of the PIOs.
PIN LIST SORTED BY FUNCTION 1
I
