Before you start
Checking what’s in the box
Please check that you’ve received the following supplied
accessories:
•
Remote control
•
AAA size IEC R03 dry cell batteries (to confirm system
operation) x2
•
AM loop antenna
•
FM wire antenna
•
Speaker cables (3 m/10 ft.) x4
•
Speaker cables (8 m/26 ft.) x2
•
Non-Skid Pads x20
•
Quick start guide
•
Safety Brochure
*This document is an online instruction manual. It is not
included as an accessory.
Installing the receiver
•
When installing this unit, make sure to put it on a level and
stable surface.
Don’t install it on the following places:
– on a color TV (the screen may distort)
– near a cassette deck (or close to a device that gives off a
magnetic field). This may interfere with the sound.
– in direct sunlight
– in damp or wet areas
– in extremely hot or cold areas
– in places where there is vibration or other movement
– in places that are very dusty
– in places that have hot fumes or oils (such as a kitchen)
Flow of settings on the receiver
The unit is a full-fledged AV receiver equipped with an
abundance of functions and terminals. It can be used easily
after following the procedure below to make the connections
and settings.
The colors of the steps indicate the following:
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Required setting item
Setting to be made as necessary
1
Connecting the speakers
Where you place the speakers will have a big effect on
the sound.
•
Placing the speakers (page 8)
•
Connecting the speakers (page 9)
2
Connecting the components
For surround sound, you’ll want to hook up using a
digital connection from the Blu-ray Disc/DVD player to
the receiver.
•
About video outputs connection (page 11)
•
Connecting a TV and playback components
(page 12
)
•
Connecting antennas (page 14)
•
Plugging in the receiver (page 15)
3
Power On
Make sure you’ve set the video input on your TV to
this receiver. Check the manual that came with the TV
if you don’t know how to do this.
4
Specify the size and number of speakers you’ve
connected
•
Speaker Setting (page 26)
5
The Input Assign menu (page 28)
(When using connections other than the
recommended connections.)
The HDMI Setup menu (page 29
)
(When the connected TV supports the HDMI Audio
Return Channel function.)
6
Basic playback (page 16)
•
Selecting the audio input signal (page 16)
•
Playing a USB device (page 18)
•
Choosing the listening mode (page 22)
7
Adjusting the sound as desired
•
Using the Advanced Music Optimizer (page 23)
•
Setting the Audio options (page 23)
•
Manual speaker setup (page 26)
To Next Page
