Specifications
Amplifer section
Continuous average power output of 60 watts* per
channel, min., at 8 ohms, from 20 Hz to 20 000 Hz with no
more than 0.7 %** total harmonic distortion.
Front (stereo) . . . . . . . . . . . . . . . . . . . . . . . . 60 W + 60 W
Power output (1 kHz, 6 Ω, 0.7 %) . . . . 100 W per channel
Maximum Effective Output Power
(JEITA) (1 kHz, 6 Ω, 10 %) . . . . . . . . 120 W per channel
Guaranteed speaker impedance . . . . . . . . . . 6 Ω to 16 Ω
* Measured pursuant to the Federal Trade Commission's
Trade Regulation rule on Power Output Claims for Amplifiers
** Measured by Audio Spectrum Analyzer
Audio section
Input (Sensitivity/Impedance)
LINE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250 mV/47 kΩ
Signal-to-Noise Ratio (IHF-A network, 1 kΩ shorted)
LINE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106 dB
Video Section
Signal level
Composite . . . . . . . . . . . . . . . . . . . . . . . . . .1 Vp-p (75 Ω)
Tuner Section
Frequency Range (FM) . . . . . . . . . . . 87.5 MHz to 108 MHz
Antenna Input (FM) . . . . . . . . . . . . . . . . . . 75 Ω unbalanced
Frequency Range (AM) . . . . . . . . . . . . 530 kHz to 1700 kHz
Antenna (AM). . . . . . . . . . . . . . . . . . . . . . . . . Loop antenna
BLUETOOTH section
Version. . . . . . . . . . . . . BLUETOOTH Specification Ver. 3.0
Output . . . . . . . . . . . . . BLUETOOTH Specification Class 2
Estimated line-of-sight transmission distance*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .About 10 m (33 ft.)
Frequency range . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.4 GHz
Supported BLUETOOTH profiles. . . . . . . . . . . . . . . . . A2DP
Supported Codec. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . .SBC (Subband Codec), AAC, Qualcomm
®
aptX™
* The line-of-sight transmission distance is an estimate.
Actual transmission distances supported may differ
depending on surrounding conditions.
Digital In/Out Section
HDMI terminal . . . . . . . . . . . . . . . . . . . . . . . Type A (19-pin)
HDMI output type . . . . . . . . . . . . . . . . . . . . . . . . 5 V, 55 mA
USB terminal . . . . . USB2.0 Full Speed (Type A) 5 V, 0.5 A
Speaker section
Subwoofer
Cabinet. . . . . . . . . . . . . . . . . . . . . . Bass-reflex, floor type
Speaker . . . . . . . . . . . . . . . . . . . . . . . . . 16 cm cone type
Nominal impedance . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Ω
Outline Dimension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . .230 mm (W) x 418 mm (H) x 358 mm (D)
9
1
/
16
in. (W) x 16
7
/
16
in. (H) x 14
3
/
32
in. (D)
Weight (without package). . . . . . . . . . . . . . . 5.0 kg (11 lb)
Front speakers / Surround speakers
Enclosure
Front speakers . . . . . . . . . . ....Closed-box bookshelf type
Surround speakers. . . . . . . . . Closed-box bookshelf type
System . . . . . . . . . . . . . . . . . . . . . . 7.7 cm 1-way system
Speaker . . . . . . . . . . . . . . . . . . . . . . . . .7.7 cm cone type
Nominal impedance . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Ω
Dimensions . . . .100 mm (W) x 140 mm (H) x 95 mm (D)
3
15
/
16
in. (W) x 5
1
/
2
in. (H) x 3
3
/
4
in. (D)
Weight
Front speakers . . . . . . . . . . . . . . . . . . . 0.55 kg (1 lb 3 oz)
Surround speakers. . . . . . . . . . . . . . . . 0.55 kg (1 lb 3 oz)
Center speaker
Enclosure . . . . . . . . . . . . . . . . Closed-box bookshelf type
System . . . . . . . . . . . . . . . . . . . . . . 7.7 cm 1-way system
Speaker . . . . . . . . . . . . . . . . . . . . . . . . .7.7 cm cone type
Nominal impedance . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Ω
Dimensions . . . . .240 mm (W) x 95 mm (H) x 95 mm (D)
9
7
/
16
in. (W) x 3
3
/
4
in. (H) x 3
3
/
4
in. (D)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . 0.67 kg (1 lb 7 oz)
Miscellaneous
Power Requirements . . . . . . . . . . . . . . . . . AC 120 V, 60 Hz
Power Consumption. . . . . . . . . . . . . . . . . . . . . . . . . . 190 W
In standby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.35 W
Dimensions . . . 435 mm (W) x 168 mm (H) x 326.5 mm (D)
17
1
/
8
in. (W) x 6
5
/
8
in. (H) x 12
13
/
16
in. (D)
Weight (without package). . . . . . . . . . . . 7.7 kg (16 lb 15 oz)
Furnished Parts
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Dry cell batteries (AAA size IEC R03) . . . . . . . . . . . . . . . . 2
AM loop antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FM wire antenna. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Speaker cables (3 m/10 ft.) . . . . . . . . . . . . . . . . . . . . . . . . 4
Speaker cables (8 m/26 ft.) . . . . . . . . . . . . . . . . . . . . . . . . 2
Non-Skid Pads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Quick start guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Brochure
Note
• Specifications and the design are subject to possible
modifications without notice, due to improvements.
