1/70 PAGE
HT-R558
<Note>
Parts marked by "NSP" are generally unavailable because <Notes>
they are not in our Master Spare Parts List. (B) : Black model
(S) : Silver model
<MPP> : 230V,CE(European) country model
<MPA> : 230V,Australian model
<MMQ> : 220/230-240V,Hong kong model
<MMR> : 220/230-240V,Chinese model
HT-R558
EXPLODED VIEW PARTS LIST
REF. NO
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
Q6050 TR 2SC5198-O 1 2203063 <B / S>
Q6050 or TR 2SC4468-O ( 1) 2202523 <B / S>
Q6050 or TR 2SC4468-P ( 1) 2202526 <B / S>
Q6050 or TR 2SC5198-R ( 1) 2203062 <B / S>
Q6050A ISO SHEET AC238 2 223024 <B / S>
Q6050B ISO SHEET ISO SHEET 4 223050 <B / S>
Q6051 TR 2SC5198-O 1 2203063 <B / S>
Q6051 or TR 2SC4468-O ( 1) 2202523 <B / S>
Q6051 or TR 2SC4468-P ( 1) 2202526 <B / S>
Q6051 or TR 2SC5198-R ( 1) 2203062 <B / S>
Q6052 TR 2SC5198-O 1 2203063 <B / S>
Q6052 or TR 2SC4468-O ( 1) 2202523 <B / S>
Q6052 or TR 2SC4468-P ( 1) 2202526 <B / S>
Q6052 or TR 2SC5198-R ( 1) 2203062 <B / S>
Q6053 TR 2SC5198-O 1 2203063 <B / S>
Q6053 or TR 2SC4468-O ( 1) 2202523 <B / S>
Q6053 or TR 2SC4468-P ( 1) 2202526 <B / S>
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
