Onkyo HT-R560 Service Manual

5/69 PAGE
EXPLODED
F901 FUSE 4A-SE-EAK 1 252077GR
!, <MPP>
EXPLODED
F901 or FUSE 4A-SE-TL250V (1) 252277GR
!, <MPP>
EXPLODED
F901C LABEL T4AL250V 1 29361732A
<MPP>
EXPLODED
F6901 FUSE 10A-UL/T-233 1 252330GR
!
EXPLODED
F6901 or FUSE 10A-T/UL-ST2 (1) 252333GR
!
EXPLODED
F6902 FUSE 10A-UL/T-233 1 252330GR
!
EXPLODED
F6902 or FUSE 10A-T/UL-ST2 (1) 252333GR
!
EXPLODED
U01 AMPLIFIER PC board ass'y NAAF-9419-1C* 1 1B211519-1C
<MDD, MDC>
EXPLODED
U01 AMPLIFIER PC board ass'y NAAF-9419-1D* 1 1B211519-1D
<MPP>
EXPLODED
U02
TRANS. SEC TERMINAL PC board ass'y
NAPS-9420-1C 1 1B211520-1C
<MDD, MDC>
EXPLODED
U02
TRANS. SEC TERMINAL PC board ass'y
NAPS-9420-1D 1 1B211520-1D
<MPP>
EXPLODED
U03
THERMAL SENSOR PC board ass'y
NAETC-9421-1 1 ---
NSP
EXPLODED
U04 HOLDER PC board NAETC-9422-1 1 ---
NSP
EXPLODED
U10 DISPLAY PC board ass'y NADIS-9430-1D* 1 1B211530-1D
<MDD, MDC>
EXPLODED
U10 DISPLAY PC board ass'y NADIS-9430-1E* 1 1B211530-1E
<MPP>
EXPLODED
U11 SWITCH PC board ass'y NADIS-9431-1D 1 1B211531-1D
<MDD, MDC>
EXPLODED
U11 SWITCH PC board ass'y NADIS-9431-1E 1 1B211531-1E
<MPP>
EXPLODED
U12 POWER SUPPLY PC board ass'y NAPS-9432-1D 1 1B211532-1D
<MDD, MDC>
EXPLODED
U12 POWER SUPPLY PC board ass'y NAPS-9432-1E 1 1B211532-1E
<MPP>
EXPLODED
U13
TRANS. SEC. TERMINAL PC board ass'y
NAPS-9433-1D 1 1B211533-1D
<MDD, MDC>
EXPLODED
U13
TRANS. SEC. TERMINAL PC board ass'y
NAPS-9433-1E 1 1B211533-1E
<MPP>
EXPLODED
U14 HEADPHONE JACK PC board ass'y NAETC-9435-1 1 ---
NSP
EXPLODED
U17 HOLDER PC board ass'y NAETC-9441-1 1 ---
NSP
EXPLODED
U30 MICROPROCESSOR PC board ass'y NADG-9457-1F* 1 1B211557-1F
<MDD, MDC>
EXPLODED
U30 MICROPROCESSOR PC board ass'y NADG-9457-1G* 1 1B211557-1G
<MPP>
EXPLODED
U31 SIRIUS PC board ass'y NARF-9458-1F 1 1B211558-1F
<MDD, MDC>
EXPLODED
U36 VIDEO PC board ass'y NAVD-9467-1E* 1 1B211567-1E
<MDD, MDC>
EXPLODED
U36 VIDEO PC board ass'y NAVD-9467-1F* 1 1B211567-1F
<MPP>
EXPLODED
U37
SPEAKER TERMINAL PC board ass'y
NATRM-9468-1E 1 1B211568-1E
<MDD, MDC>
EXPLODED
U37
SPEAKER TERMINAL PC board ass'y
NATRM-9468-1F 1 1B211568-1F
<MPP>
EXPLODED
U42 HDMI PC board ass'y NAHDM-9475-1A* 1 1B211575-1A
EXPLODED
U45 TUNER UNIT ENG06507QFUS 1 240156
<MDD, MDC>
EXPLODED
U45 or TUNER UNIT FAE385-A11US (1) 240152
<MDD, MDC>
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Onkyo HT-R560 Specifications

General

Type	AV Receiver
Number of Channels	7.1
HDMI Outputs	1
Component Video Outputs	1
Digital Audio Inputs (Optical)	2
Digital Audio Inputs (Coaxial)	1
Headphone Jack	Yes
Tuner Presets	40
Amplifier Type	Discrete
Frequency Response	10 Hz - 100 kHz
Input Sensitivity	200 mV
Signal-to-Noise Ratio	100 dB
Speaker Impedance	6 Ohms
USB Port	No
Bluetooth	No
Wi-Fi	No
