HT-R560
PC BOARD PARTS LIS
PCB1
U01
AMPLIFIER PC BOARD (NAAF-9419-1C / 1D)
PCB1
U02
TRANS. SEC. TERMINAL PC BOARD (NAPS-9420-1C / 1D)
PCB1
U03
THERMAL SENSOR PC BOARD (NAETC-9421-1C / 1D)
PCB1
PCB1
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PCB1
Q5000 TR 2SC2240-BL(TPE2_F) 1 2211406T
PCB1
Q5001 TR 2SC2240-BL(TPE2_F) 1 2211406T
PCB1
Q5002 TR 2SC2240-BL(TPE2_F) 1 2211406T
PCB1
Q5003 TR 2SC2240-BL(TPE2_F) 1 2211406T
PCB1
Q5004 TR 2SC2240-BL(TPE2_F) 1 2211406T
PCB1
Q5005 TR 2SC2240-BL(TPE2_F) 1 2211406T
PCB1
Q5006 TR 2SC2240-BL(TPE2_F) 1 2211406T
PCB1
Q5010 TR 2SC2240-BL(TPE2_F) 1 2211406T
PCB1
Q5011 TR 2SC2240-BL(TPE2_F) 1 2211406T
PCB1
Q5012 TR 2SC2240-BL(TPE2_F) 1 2211406T
PCB1
Q5013 TR 2SC2240-BL(TPE2_F) 1 2211406T
PCB1
Q5014 TR 2SC2240-BL(TPE2_F) 1 2211406T
PCB1
Q5015 TR 2SC2240-BL(TPE2_F) 1 2211406T
PCB1
Q5016 TR 2SC2240-BL(TPE2_F) 1 2211406T
PCB1
Q5030 TR 2SA949-Y(TPE6_F) 1 2211354T
PCB1
Q5031 TR 2SA949-Y(TPE6_F) 1 2211354T
PCB1
Q5032 TR 2SA949-Y(TPE6_F) 1 2211354T
PCB1
Q5033 TR 2SA949-Y(TPE6_F) 1 2211354T
PCB1
Q5034 TR 2SA949-Y(TPE6_F) 1 2211354T
PCB1
Q5035 TR 2SA949-Y(TPE6_F) 1 2211354T
PCB1
Q5036 TR 2SA949-Y(TPE6_F) 1 2211354T
PCB1
Q5040 TR 2SC2229-Y(TPE6_F) 1 2211634T
