Onkyo HT-R570 Service Manual

HT-R570
<Note>
Parts marked by "NSP" are generally unavailable because <Notes>
they are not in our Master Spare Parts List. <B> : Black model
<S> : Silver model
<DC> : 120V,Canadian model
<DD> : 120V,USA model
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[TUNER UNIT]
EXPLODED
U001 AF-AS AMPLIFIER PC BOARD BAAF-0008-1E 1 1B232508-1E N
EXPLODED
U0011
TRANS.SEL.TERMINAL PC BOARD
BAPS-0009-1E {1} 1B232509-1E N NSP included in "AF-AS"
EXPLODED
U0012
TRANS.SEL.TERMINAL PC BOARD
BAPS-0010-1E {1} 1B232510-1E N NSP included in "AF-AS"
EXPLODED
U0013
THERMAL SENSOR PC BOARD
BAETC-0011-1E {1} 1B232511-1E N NSP included in "AF-AS"
EXPLODED
U0014
ETC PC BOARD
BAETC-0012-1E {1} 1B232512-1E N NSP included in "AF-AS"
EXPLODED
U002 DG-AS CPU/CODEC PC BOARD BADG-0022-1K 1 1B232522-1K N Order please do at 2 units
EXPLODED
U0021 UNIVERSAL PORT PC BOARD BAETC-0023-1K {1} 1B232523-1K N NSP included in "DG-AS"
EXPLODED
U003 DIS-AS DISPLAY PC BOARD BADIS-0036-1M 1 1B232536-1M N
EXPLODED
U0031 DISPLAY PC BOARD BADIS-0037-1M {1} 1B232537-1M N NSP included in "DIS-AS"
EXPLODED
U0032
VIDEO PC BOARD
BAVD-0038-1M {1} 1B232538-1M N NSP included in "DIS-AS"
EXPLODED
U0033
POWER SUPPLY PC BOARD
BAPS-0039-1M {1} 1B232539-1M N NSP included in "DIS-AS"
EXPLODED
U0034
HP LACK PC BOARD
BAETC-0040-1M {1} 1B232540-1M N NSP included in "DIS-AS"
EXPLODED
U004 HDM-AS HDMI PC BOARD BAHDM-0058-1B 1 1B232558-1B Order please do at 4units
EXPLODED
U005 TRM-AS SPEAKERS TERMINAL PC BOARD BATRM-0029-1D 1 1B232529-1D N Order please do at 2 units
EXPLODED
U010 TUNER UNIT FAEH06-A01US 1 240166
[SEMI CONDUCTOR]
EXPLODED
Q6050 TR 2SC5198-O 1 2203063
EXPLODED
Q6050 or TR 2SC4468-O ( 1) 2202523
EXPLODED
Q6050 or TR 2SC4468-Y ( 1) 2202524
EXPLODED
Q6050 or TR 2SC4468-P ( 1) 2202526
EXPLODED
Q6050 or TR 2SC5198-R ( 1) 2203062
EXPLODED
Q6050 or TR MN130S-O ( 1) 2203663
