Onkyo HT-R570 - Page 58

PCB-1
RL6901 RELAY NRL-1P10A-DC12-140 1 25065584
PCB-1
RL6901 or RELAY NRL-1P10A-DC12-143 ( 1) 25065588
PCB-1
RL6902 RELAY NRL-1P10A-DC12-140 1 25065584
PCB-1
RL6902 or RELAY NRL-1P10A-DC12-143 ( 1) 25065588
U002 CPU/CODEC PC BOARD (BADG-0022-1K)
U00021 UNIVERSAL PORT PC BOARD (BAETC-0023-1K)
CIRCUIT. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[TUNER UNIT]
PCB-2
U131 PHT CP JSR1165-001recieving 1 24120143
PCB-2
U131 or PHT CP GP1FAV51RK0F ( 1) 24120129
PCB-2
U132 PHT CP JSR1165-001recieving 1 24120143
PCB-2
U132 or PHT CP GP1FAV51RK0F ( 1) 24120129
[SEMI CONDUCTOR]
PCB-2
D110 C-DIODE KDS4148U 1 223283R2
PCB-2
D110 or C-DIODE 1SS352 ( 1) 223234R2
PCB-2
D110 or C-DIODE MA2J111 ( 1) 223279R2
PCB-2
D111 C-DIODE KDS4148U 1 223283R2
PCB-2
D111 or C-DIODE 1SS352 ( 1) 223234R2
PCB-2
D111 or C-DIODE MA2J111 ( 1) 223279R2
PCB-2
D112 ZENER D UDZS10B 1 224551000R2
PCB-2
D113 C-DIODE KDS4148U 1 223283R2
PCB-2
D114 C-DIODE KDS4148U 1 223283R2
PCB-2
D181 C-DIODE KDS4148U 1 223283R2
PCB-2
D181 or C-DIODE 1SS352 ( 1) 223234R2
PCB-2
D181 or C-DIODE MA2J111 ( 1) 223279R2
PCB-2
D182 C-DIODE KDS4148U 1 223283R2
PCB-2
D182 or C-DIODE 1SS352 ( 1) 223234R2
PCB-2
D182 or C-DIODE MA2J111 ( 1) 223279R2
PCB-2
D183 DIODE RL1N4003 1 22380260T
PCB-2
D601 C-DIODE KDS4148U 1 223283R2
PCB-2
D601 or C-DIODE 1SS352 ( 1) 223234R2
PCB-2
D601 or C-DIODE MA2J111 ( 1) 223279R2
PCB-2
D701 C-DIODE KDS4148U 1 223283R2
PCB-2
D701 or C-DIODE 1SS352 ( 1) 223234R2
PCB-2
D701 or C-DIODE MA2J111 ( 1) 223279R2
PCB-2
D702 C-DIODE KDS4148U 1 223283R2
