Onkyo HT-R570 - Page 59

PCB-2
D702 or C-DIODE 1SS352 ( 1) 223234R2
PCB-2
D702 or C-DIODE MA2J111 ( 1) 223279R2
PCB-2
Q111 TR 2SC2235-Y(TPE6_F) 1 2211654T
PCB-2
Q131 IC 74HCU04F 1 222740046R2
PCB-2
Q131 or IC TC74HCU04AF ( 1) 222740046R2TO
PCB-2
Q153 IC R1EX25064ASA00A 1 22242581R2
PCB-2
Q171 IC TC7WU04FU(TE12L_F) 1 22240935R2
PCB-2
Q181 TR KRC105S 1 2217290R2
PCB-2
Q181 or TR RN1405 ( 1) 2214500R2
PCB-2
Q301 IC CS42518-CQZR-D 1 22242229R2
PCB-2
Q400 IC NJM4580M-D 1 22241448R2
PCB-2
Q401 IC NJM4580M-D 1 22241448R2
PCB-2
Q402 IC NJM4580M-D 1 22241448R2
PCB-2
Q403 IC NJM4580M-D 1 22241448R2
PCB-2
Q404 IC NJM4580M-D 1 22241448R2 <1K>
PCB-2
Q601 TR KRC104S 1 2216210R2
PCB-2
Q601 or TR RN1404 ( 1) 2214490R2
PCB-2
Q701 IC M30624MHP-481FP 1 22242615R3 <1K>
PCB-2
Q702 IC S-812C33AUA-C2N 1 22242222R2
PCB-2
Q703 IC S-812C56AUA-C3K 1 22242207R2
PCB-2
Q746 IC BH33FB1WG-TR 1 22242585R2
PCB-2
Q751 TR KRC104S 1 2216210R2
PCB-2
Q751 or TR RN1404 ( 1) 2214490R2
PCB-2
Q752 TR KRA102S 1 2216220R2
PCB-2
Q752 or TR RN2402 ( 1) 2214530R2
PCB-2
Q753 TR KRA107S 1 2216350R2
PCB-2
Q753 or TR RN2407(TE85L_F) ( 1) 2216360R2
PCB-2
Q754 TR KRC102S 1 2216190R2
PCB-2
Q754 or TR RN1402 ( 1) 2214470R2
PCB-2
Q755 TR KRA107S 1 2216350R2
PCB-2
Q755 or TR RN2407(TE85L_F) ( 1) 2216360R2
PCB-2
Q756 TR KRC102S 1 2216190R2
PCB-2
Q756 or TR RN1402 ( 1) 2214470R2
[TRANS COIL]
PCB-2
L131 CHOKE COIL LBC2518T2R2M 1 231364M022R2
PCB-2
L132 CHOKE COIL LBC2518T2R2M 1 231364M022R2 <1K>
PCB-2
L133 CHOKE COIL LBC2518T470M 1 231364M470R2
PCB-2
L134 CHOKE COIL LBC2518T470M 1 231364M470R2
PCB-2
L136 CHOKE COIL LBC2518T4R7M 1 231364M047R2
