Onkyo HT-R590

3/58 PAGE
EV
A354 HOLDER (PLATE) 6 27191337 <MDC, MDD, MDS, MMK, MMQ>
EV
A360 LABEL (COVER) 1 29390767
EV
A362 LABEL HOOKUP-ONKYO 1 29363194 <MDC, MDD, MDS>
EV
A364 CUSHION T5 x Φ12 x 6 2 28141867
EV
[TRANS COIL]
EV
T901 P TRANS NPT-1604D 1 2302012
!
<MDC, MDD, MDS>
EV
T901 P TRANS NPT-1604M 1 2302014
!
<MMK, MMQ>
EV
[SW TRM]
EV
F6901 FUSE 10A-UL/T-233 1 252330GR
!
EV
F6901 or FUSE 10A-T/UL-ST2 ( 1) 252333GR
!
EV
F6902 FUSE 10A-UL/T-233 1 252330GR
!
EV
F6902 or FUSE 10A-T/UL-ST2 ( 1) 252333GR
!
EV
F901 FUSE 4A-SE-EAK 1 252077GR
!
<MMK, MMQ>
EV
F901 FUSE 8A-UL/T-233 1 252329GR
!
<MDC, MDD, MDS>
EV
F901 or FUSE 8A-T/UL-ST2 ( 1) 252261GR
!
<MDC, MDD, MDS>
EV
F901 or FUSE 4A-SE-TL250V ( 1) 252277GR
!
<MMK, MMQ>
EV
F901E LABEL T4AL250V 1 29361732A <MMK, MMQ>
EV
P101 FFC NCFC7-091512 1 2047091512
EV
P2800 FFC NCFC5-091012 1 2045091012
EV
P3101 SOCKET AS NSAS-10P1924 1 2009991224UL
EV
P6601A P RIVET JB-407A-C 14 880052 <MMK, MMQ>
EV
P701 FFC NCFC5-232212 1 2045232212
N
EV
P703 FFC NCFC5-072512 1 2045072512
N
EV
P901 AC CORD AS-BS 1 253198LTK
!
<MMQ>
EV
P901 AC CORD AS-CEE-2 1 253306VOL
!
<MMK>
EV
P901 AC CORD AS-UC-2 1 253368AYUN
!
<MDC, MDD>
EV
P901 or AC CORD AS-UC-2 ( 1) 253368BLTK
!
<MDC, MDD>
EV
P901 or AC CORD AS-CEE-2 ( 1) 253374YUN
!
<MMK>
EV
P901B FASTON AS FASTON SOCKET 1 1F999026A
!
<MDS>
EV
P907 AC INLET R301X2PSn 1 25053358
!
<MDS>
EV
[TUNER UNIT]
EV
U001
U0010 + U0011 + U0012 + U0013 + U0014 +
U0015 + U0016 + U0017
BAAF-0621-1A * 1 1B258521-1A N <MDD, MDC, MDS>
EV
U001 BAAF-0621-1B * 1 1B258521-1B N <MMK, MMQ>
EV
U0010
P
ower
A
mp
/A
u
di
o
I
npu
t
T
erm
i
na
l
s
PC
b
oar
d
ass
'
y
BAAF-0621-1A 1 1B2585621-1A
N
<MDD, MDC, MDS>
EV
U0010 BAAF-0621-1B 1 1B2585621-1B
N
<MMK, MMQ>
EV
U0011 Center Speaker Terminal PC Board ass'y BATRM-0622-1A 1 1B2585622-1A
N
<MDD, MDC, MDS>
EV
U0011 BATRM-0622-1B 1 1B2585622-1B
N
<MMK, MMQ>
