Onkyo HT-R590

4/58 PAGE
EV
U0012 Thermal Senser PC board ass'y BAETC-0623-1A 1 1B2585623-1A
N
<MDD, MDC, MDS>
EV
U0012 BAETC-0623-1B 1 1B2585623-1B
N
<MMK, MMQ>
EV
U0013 Spacer PC board ass'y BAETC-0624-1A 1 1B2585624-1A
N
<MDD, MDC, MDS>
EV
U0013 BAETC-0624-1B 1 1B2585624-1B
N
<MMK, MMQ>
EV
U0014 Terminal PC board ass'y BAETC-0625-1A 1 1B2585625-1A
N
<MDD, MDC, MDS>
EV
U0014 BAETC-0625-1B 1 1B2585625-1B
N
<MMK, MMQ>
EV
U0015 FFC Fixture PC board ass'y BAETC-0626-1A 1 1B2585626-1A
N
<MDD, MDC, MDS>
EV
U0015 BAETC-0626-1B 1 1B2585626-1B
N
<MMK, MMQ>
EV
U0016 Power supply PC board ass'y BAETC-0627-1A 1 1B2585627-1A
N
<MDD, MDC, MDS>
EV
U0016 BAETC-0627-1B 1 1B2585627-1B
N
<MMK, MMQ>
EV
U0017 Part Fixture PC board ass'y BAETC-0764-1A 1 1B2585764-1A
N
<MDD, MDC, MDS>
EV
U0017 BAETC-0764-1B 1 1B2585764-1B
N
<MMK, MMQ>
EV
U002 U0020+U0021+U0022+U0023+U0024 BADIS-0654-1E * 1 1B258554-1E N <MDD, MDC, MDS>
EV
U002 BADIS-0654-1F * 1 1B258554-1F N <MMK, MMQ>
EV
U0020 Display PC board assy BADIS-0654-1E 1 1B2585654-1E
N
<MDD, MDC, MDS>
EV
U0020 BADIS-0654-1F 1 1B2585654-1F
N
<MMK, MMQ>
EV
U0021 Standby switch PC board ass'y BADIS-0655-1E 1 1B2585655-1E
N
<MDD, MDC, MDS>
EV
U0021 BADIS-0655-1F 1 1B2585655-1F
N
<MMK, MMQ>
EV
U0022 Video PC board ass'y BAVD-0656-1E 1 1B2585656-1E
N
<MDD, MDC, MDS>
EV
U0022 BAVD-0656-1F 1 1B2585656-1F
N
<MMK, MMQ>
EV
U0023 HP jack PC board ass'y BAETC-0658-1E 1 1B2585658-1E
N
<MDD, MDC, MDS>
EV
U0023 BAETC-0658-1F 1 1B2585658-1F
N
<MMK, MMQ>
EV
U0024 Power supply PC board ass'y BAPS-0659-1E 1 1B2585659-1E
N
<MDD, MDC, MDS>
EV
U0024 BAPS-0659-1F 1 1B2585659-1F
N
<MMK, MMQ>
EV
U003 U0030 x 2 pcs. BAHDM-0680-1A * 1 1B258580-1A N <MDD, MDC, MDS>
EV
U003 BAHDM-0680-1B * 1 1B258580-1B N <MMK, MMQ>
EV
U0030 HDMI PC board ass'y BAHDM-0680-1A 1 1B2585680-1A
N
<MDD, MDC, MDS>
EV
U0030 BAHDM-0680-1B 1 1B2585680-1B
N
<MMK, MMQ>
EV
U004 U0040 x 4 pcs. BADG-0639-1A * 1 1B258539-1A N
EV
U0040 Digital Input Terminals PC board ass'y BADG-0639-1A * 1 1B2585639-1A
N
EV
U010 TUNER UNIT KST-MW004MS1-S89S 1 240171 <MDC, MDD, MDS>
EV
U010 TUNER UNIT KST-MW104MS1-S89 1 240172 <MMK, MMQ>
HT-R590
PV
PACKING PROCEDURES PARTS LIS
T
PV
PV
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PV
[PACKING]
PV
A601 PAD AS (AS) HTR390 L & R 1 29092582A <MDC, MDD, MDS, MMK, MMQ>
