Onkyo HT-R590

9/58 PAGE
U001
D6902 or C-DIODE 1SS352 ( 1) 223234R2
U001
D6902 or C-DIODE 1SS355 ( 1) 223269R2
U001
D6902 or C-DIODE MA2J111 ( 1) 223279R2
U001
D6902 or C-DIODE KDS4148U ( 1) 223283R2
U001
D6903 C-DIODE DA2J10100 1 223303R2
U001
D6903 or C-DIODE 1SS352 ( 1) 223234R2
U001
D6903 or C-DIODE 1SS355 ( 1) 223269R2
U001
D6903 or C-DIODE MA2J111 ( 1) 223279R2
U001
D6903 or C-DIODE KDS4148U ( 1) 223283R2
U001
D960 DIODE RL1N4003 1 22380260T
U001
D961 DIODE RL1N4003 1 22380260T
U001
D964 ZENER D DZ2J360M0L 1 224763600R2 N <MDC, MDD, MDS, MMK, MMQ>
U001
D964 or ZENER D UDZS36B ( 1) 224553600R2 <MDC, MDD, MDS, MMK, MMQ>
U001
Q4001 IC R2A15218FP 1 22242605R3
U001
Q4003 IC NJM4580M-D 1 22241448R2
U001
Q4100 TR RN1441 1 2215410R2
U001
Q4101 TR RN1441 1 2215410R2
U001
Q4102 TR RN1441 1 2215410R2
U001
Q4103 TR RN1441 1 2215410R2
U001
Q4104 TR RN1441 1 2215410R2
U001
Q4105 TR RN1441 1 2215410R2
U001
Q4106 TR RN1441 1 2215410R2
U001
Q4107 TR RN1441 1 2215410R2
U001
Q4117 TR RN1441 1 2215410R2
U001
Q4130 IC NJM4580M-D 1 22241448R2
U001
Q4170 IC 78M15HF(NJM78M15FA) 1 222780155JRC
U001
Q4170 or IC UPC78M15AHF-AZ ( 1) 222780155NEC
U001
Q4170A HEAT SINK RAD-196 1 27160545
U001
Q4170B SCREW 3P+10FN(3BC) 1 82143010GR
U001
Q4171 IC 79M15HF(NJM79M15FA) 1 222790155JRC
U001
Q4171 or IC UPC79M15HF-AZ ( 1) 222790155NEC
U001
Q4171B SCREW 3P+10FN(3BC) 1 82143010GR
U001
Q4400 IC NJM4580M-D 1 22241448R2 <MDC, MDD, MDS, MMK, MMQ>
U001
Q4401 TR 2SC2235-Y(TPE6_F) 1 2211654T <MDC, MDD, MDS, MMK, MMQ>
U001
[NOTICE]
U001
Q6001, Q6002, Q6003 and the surrounding parts have been changed as follows in the middle of production. Refer to SCHEMATIC-DIAGRAM-4(AMP. SECTION)
U001
Change C6120, C6121 and C6122 at the same time when Q6001 is changed.
U001
Q6001
IC STK-443-530-E 1 222148 BEFORE
U001
↓↓
