Onkyo HT-R590 - Page 36

10/58 PAGE
U001
IC
STK-443-530N-E
1
222152
AFTER
U001
C6120 C-CERA C CC725CH1H-101J1 0 342101014R1 BEFORE
U001
↓
U001
C-CERA C CC725CH1H-101J1
1
342101014R1 AFTER
U001
C6121 C-CERA C CC725CH1H-101J1 0 342101014R1 BEFORE
U001
↓
U001
C-CERA C CC725CH1H-101J1
1
342101014R1 AFTER
U001
C6122 C-CERA C CC725CH1H-101J1 0 342101014R1 BEFORE
U001
↓
U001
C-CERA C CC725CH1H-101J1
1
342101014R1 AFTER
U001
Change C6123 and C6124 at the same time when Q6002 is changed.
U001
Q6002
IC STK-442-730-E 1 222150 N BEFORE
U001
↓↓
U001
IC
STK-442-730N-E
1
222153
AFTER
U001
C6123 C-CERA C CC725CH1H-561J1 0 342105614R1 BEFORE
U001
↓
U001
C-CERA C CC725CH1H-561J1
1
342105614R1 AFTER
U001
C6124 C-CERA C CC725CH1H-561J1 0 342105614R1 BEFORE
U001
↓
U001
C-CERA C CC725CH1H-561J1
1
342105614R1 AFTER
U001
Change C6125 and C6126 at the same time when Q6003 is changed.
U001
Q6003
IC STK-442-730-E 1 222150 N BEFORE
U001
↓↓
U001
IC
STK-442-730N-E
1
222153
AFTER
U001
C6125 C-CERA C CC725CH1H-561J1 0 342105614R1 BEFORE
U001
↓
U001
C-CERA C CC725CH1H-561J1
1
342105614R1 AFTER
U001
C6126 C-CERA C CC725CH1H-561J1 0 342105614R1 BEFORE
U001
↓
U001
C-CERA C CC725CH1H-561J1
1
342105614R1 AFTER
U001
Q6010 TR 2SC2240-BL(TPE2_F) 1 2211406T
U001
Q6011 TR 2SC2240-BL(TPE2_F) 1 2211406T
U001
Q6012 TR 2SC2240-BL(TPE2_F) 1 2211406T
U001
Q6013 TR 2SC2240-BL(TPE2_F) 1 2211406T
U001
Q6014 TR 2SC2240-BL(TPE2_F) 1 2211406T
U001
Q6015 TR 2SC2240-BL(TPE2_F) 1 2211406T <MDC, MDD, MDS, MMK, MMQ>
U001
Q6016 TR 2SC2240-BL(TPE2_F) 1 2211406T <MDC, MDD, MDS, MMK, MMQ>
U001
Q6021 TR 2SA1163-BL(TE85L_F) 1 2216756R2
U001
Q6022 TR 2SC2240-BL(TPE2_F) 1 2211406T
