CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D1000 C-DIODE KDS4148U 1 223283R2
D1000 or C-DIODE 1SS352 ( 1) 223234R2
D1000 or C-DIODE 1SS355 ( 1) 223269R2
D1000 or C-DIODE MA2J111 ( 1) 223279R2
D1000 or C-DIODE DA2J10100 ( 1) 223303R2
D1001 C-DIODE KDS4148U 1 223283R2
D1001 or C-DIODE 1SS352 ( 1) 223234R2
D1001 or C-DIODE 1SS355 ( 1) 223269R2
D1001 or C-DIODE MA2J111 ( 1) 223279R2
D1001 or C-DIODE DA2J10100 ( 1) 223303R2
D6600 C-DIODE KDS4148U 1 223283R2
D6600 or C-DIODE 1SS352 ( 1) 223234R2
D6600 or C-DIODE 1SS355 ( 1) 223269R2
D6600 or C-DIODE MA2J111 ( 1) 223279R2
D6600 or C-DIODE DA2J10100 ( 1) 223303R2
D6603 C-DIODE KDS4148U 1 223283R2
D6603 or C-DIODE 1SS352 ( 1) 223234R2
D6603 or C-DIODE 1SS355 ( 1) 223269R2
D6603 or C-DIODE MA2J111 ( 1) 223279R2
D6603 or C-DIODE DA2J10100 ( 1) 223303R2
D6605 C-DIODE KDS4148U 1 223283R2
D6605 or C-DIODE 1SS352 ( 1) 223234R2
D6605 or C-DIODE 1SS355 ( 1) 223269R2
D6605 or C-DIODE MA2J111 ( 1) 223279R2
D6605 or C-DIODE DA2J10100 ( 1) 223303R2
Q1000 IC TC74HCU04AF 1 222740046R2TO
Q6601 TR KRC105S 1 2217290R2
Q6602 TR KRC105S 1 2217290R2
Q6603 TR KRC105S 1 2217290R2
[TRANS COIL]
L1000 CHOKE COIL LBC2518T2R2M 1 231364M022R2
L1001 CHOKE COIL LBC2518T2R2M 1 231364M022R2
L1002 CHOKE COIL LBC2518T2R2M 1 231364M022R2
L1003 CHOKE COIL LBC2518T470M 1 231364M470R2
L1004 CHOKE COIL LBC2518T470M 1 231364M470R2
L1005 EMIFIL BK1608HS102-T 1 230955R2
L1006 EMIFIL BK1608HS102-T 1 230955R2
L6600 S-COIL SC-0.8X5.5X18.5T 1 231431S <B MMK, MMQ>
L6600 or S-COIL PI-ROD002-0083 ( 1) 231454S <B MMK, MMQ>
L6600 or S-COIL SC2-0.8X5.5X18.5T ( 1) 231455S <B MMK, MMQ>
L6601 S-COIL SC-0.8X5.5X18.5T 1 231431S <B MMK, MMQ>
L6601 or S-COIL PI-ROD002-0083 ( 1) 231454S <B MMK, MMQ>
L6601 or S-COIL SC2-0.8X5.5X18.5T ( 1) 231455S <B MMK, MMQ>
L6602 S-COIL SC-0.8X5.5X18.5T 1 231431S <B MMK, MMQ>
L6602 or S-COIL PI-ROD002-0083 ( 1) 231454S <B MMK, MMQ>
L6602 or S-COIL SC2-0.8X5.5X18.5T ( 1) 231455S <B MMK, MMQ>
L6603 S-COIL SC-0.8X5.5X18.5T 1 231431S <B MMK, MMQ>
L6603 or S-COIL PI-ROD002-0083 ( 1) 231454S <B MMK, MMQ>
L6603 or S-COIL SC2-0.8X5.5X18.5T ( 1) 231455S <B MMK, MMQ>
L6604 S-COIL SC-0.8X5.5X18.5T 1 231431S <B MMK, MMQ>
L6604 or S-COIL PI-ROD002-0083 ( 1) 231454S <B MMK, MMQ>
L6604 or S-COIL SC2-0.8X5.5X18.5T ( 1) 231455S <B MMK, MMQ>
L6605 S-COIL SC-0.8X5.5X18.5T 1 231431S <B MMK, MMQ>
L6605 or S-COIL PI-ROD002-0083 ( 1) 231454S <B MMK, MMQ>
L6605 or S-COIL SC2-0.8X5.5X18.5T ( 1) 231455S <B MMK, MMQ>
L6606 S-COIL SC-0.8X5.5X18.5T 1 231431S <B MMK, MMQ>
L6606 or S-COIL PI-ROD002-0083 ( 1) 231454S <B MMK, MMQ>
L6606 or S-COIL SC2-0.8X5.5X18.5T ( 1) 231455S <B MMK, MMQ>
[CAPACITOR]
C1000 C-CERA C CK725F1E-104Z1 1 332161040R1
C1001 C-CERA C CC725CH1H-101J1 1 342101014R1
C1002 C-CERA C CC725CH1H-101J1 1 342101014R1
C1003 C-CERA C CK725B1C-104K1 1 332121045R1
C1004 C-CERA C CK725B1C-104K1 1 332121045R1
C1005 C-CERA C CC725CH1H-080D1 1 342100802R1
