Onkyo HT-R591B

21/38 PAGE
R6690 METAL O R RS1/2WBJ-10 1 443521004T
R6691 METAL O R RS1/2WBJ-390 1 443523914T
R6692 METAL O R RS1/2WBJ-390 1 443523914T
[SW TRM]
JL600B SOCKET NSCT-7P99 1 25050271
JL603B SOCKET NSCT-9P101 1 25050273
JL605B SOCKET NSCT-5P97 1 25050269
JL620B WIRE TRAP NPLG-7P590 1 25055628
P1000 ST JACK MSJ-035-22 1 25045887
P1001 PIN JACK NPJ-2PDOO626 1 25045847
P5502A SOCKET NSCT-20P2200 1 25052303
P5503A SOCKET NSCT-7P2187 1 25052290
P5504A SOCKET NSCT-13P2193 1 25052296
P5510A TRM NTM-1P233(M1969) 1 25060302
P6601 TRM NTM-2PDMCR400 1 25060472
P6602 TRM NTM-4PDMNRR420 1 25060492
P6603 TRM NTM-4PDMNRR420 1 25060492
P6604 TRM NTM-4PDMNRR420 1 25060492
P703B SOCKET NSCT-7P2425 1 25052528
P8001A SOCKET NSCT-29P2447 1 25052550
P8003B PLUG NPLG-9P0964 1 25056014
P8004A SOCKET NSCT-7P2398 1 25052501
RL660 RELAY NRL-2P5A-DC24-129 1 25065563A
RL660 or RELAY NRL-2P5A-DC24-193 ( 1) 25065703
RL660 or RELAY NRL-2P8A-DC24-201 ( 1) 25065718
RL662 RELAY NRL-2P5A-DC24-129 1 25065563A
RL662 or RELAY NRL-2P5A-DC24-193 ( 1) 25065703
RL662 or RELAY NRL-2P8A-DC24-201 ( 1) 25065718
RL663 RELAY NRL-2P5A-DC24-129 1 25065563A
RL663 or RELAY NRL-2P5A-DC24-193 ( 1) 25065703
RL663 or RELAY NRL-2P8A-DC24-201 ( 1) 25065718
RL665 RELAY NRL-2P5A-DC24-129 1 25065563A
RL665 or RELAY NRL-2P5A-DC24-193 ( 1) 25065703
RL665 or RELAY NRL-2P8A-DC24-201 ( 1) 25065718
[TUNER UNIT]
U1001 PHT CP JSR1165-001recieving 1 24120143
U1002 PHT CP JSR1165-001recieving 1 24120143
U004
U0040 ～
～～
～ U0044 BADIS-0654-3E/3F *
U0040 DISPLAY PC BOARD ASS'Y BADIS-0654-3E/3F
U0041 SWITCH PC BOARD ASS'Y BADIS-0655-3E/3F
U0042 VIDEO PC BOARD ASS'Y BAVD-0656-3E/3F
U0043 PHONE JACK PC BOARD ASS'Y BAETC-0658-3E/3F
U0044 POWER SUPPLY PC BOARD ASS'Y BAPS-0659-3E/3F
CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D7002 ZENER D DZ2J082M0L 1 224760820R2
D7002 or ZENER D UDZS8.2B ( 1) 224550820R2
D7033 ZENER D DZ2J039M0L 1 224760390R2
D7033 or ZENER D UDZS3.9B ( 1) 224550390R2
D7152 LED SLI-343Y8C-TE7 1 225490T
D7301 C-DIODE DA2J10100 1 223303R2
D7301 or C-DIODE 1SS352 ( 1) 223234R2
D7301 or C-DIODE 1SS355 ( 1) 223269R2
D7301 or C-DIODE MA2J111 ( 1) 223279R2
D7301 or C-DIODE KDS4148U ( 1) 223283R2
D7302 C-DIODE DA2J10100 1 223303R2
D7302 or C-DIODE 1SS352 ( 1) 223234R2
D7302 or C-DIODE 1SS355 ( 1) 223269R2
D7302 or C-DIODE MA2J111 ( 1) 223279R2
D7302 or C-DIODE KDS4148U ( 1) 223283R2
D7401 ZENER D DZ2J051M0L 1 224760510R2
<B MMK, MMQ, B MDC, MDD, MDS>
D7401 or ZENER D UDZS5.1B ( 1) 224550510R2
<B MMK, MMQ, B MDC, MDD, MDS>
D7411 ZENER D DZ2J068M0L 1 224760680R2
<B MMK, MMQ, B MDC, MDD, MDS>
D7411 or ZENER D UDZS6.8B ( 1) 224550680R2
<B MMK, MMQ, B MDC, MDD, MDS>
D7412 ZENER D DZ2J068M0L 1 224760680R2
<B MMK, MMQ, B MDC, MDD, MDS>
D7412 or ZENER D UDZS6.8B ( 1) 224550680R2
<B MMK, MMQ, B MDC, MDD, MDS>
