HT-R670
HT-R670
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
<Notes>
<DC> : 120V,Canadian model
<MO> : 220/230-240V,Saidi Arabian model
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN)
[SEMI CONDUCTOR]
Q6050 TR 2SC5198-O 1 2203063
Q6050 or TR 2SC4468-O ( 1) 2202523
Q6050 or TR 2SC4468-Y ( 1) 2202524
Q6050 or TR 2SC4468-P ( 1) 2202526
Q6050 or TR 2SC5198-R ( 1) 2203062
Q6050 or TR MN130S-O ( 1) 2203663
Q6050 or TR MN130S-Y ( 1) 2203664
Q6050 or TR MN130S-P ( 1) 2203666
Q6050A ISO SHEET AC238 2 223024
Q6050B ISO SHEET ISO SHEET 6 223050
Q6051 TR 2SC5198-O 1 2203063
Q6051 or TR 2SC4468-O ( 1) 2202523
Q6051 or TR 2SC4468-Y ( 1) 2202524
Q6051 or TR 2SC4468-P ( 1) 2202526
Q6051 or TR 2SC5198-R ( 1) 2203062
Q6051 or TR MN130S-O ( 1) 2203663
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
