8/135 PAGE
A993 ANT COIL NMA-3057 1 232140
A994 FM ANT AS Type W 1 292191
HT-RC270
PC BOARD PARTS LIS
U001 U0010~U0016 BAAMP-0444-1A * 1 1B248544-1A N
U0010 AMP (FINAL STAGE) PC BOARD AS BAAMP-0444-1A 1 1B2485444-1A N
U0011 VOLTAGE AMP PC BOARD AS BACLA-0445-1A 1 1B2485445-1A N
U0012 AMP HOLD PC BOARD AS BAETC-0446-1A 1 1B2485446-1A N
U0013 AMP HOLD PC BOARD AS BAETC-0447-1A 1 1B2485447-1A N
U0014 THERMAL PC BOARD AS BAETC-0448-1A 1 1B2485448-1A N
U0015 THERMAL PCB HOLD PC BOARD AS BAETC-0449-1A 1 1B2485449-1A N
U0016 HOLD FRONT HDMI CABLE PC BOARD AS BAETC-0455-1A 1 1B2485455-1A N
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN)
REMARKS
[SEMI CONDUCTOR]
D5000 ZENER D MTZJ5.6B 1 224470562T
D5001 ZENER D MTZJ5.6B 1 224470562T
D5002 ZENER D MTZJ5.6B 1 224470562T
D5003 ZENER D MTZJ5.6B 1 224470562T
D5004 ZENER D MTZJ5.6B 1 224470562T
D5005 ZENER D MTZJ5.6B 1 224470562T
D5006 ZENER D MTZJ5.6B 1 224470562T
D6000 DIODE 1SS133 1 223163T
D6001 DIODE 1SS133 1 223163T
D6002 DIODE 1SS133 1 223163T
D6003 DIODE 1SS133 1 223163T
D6004 DIODE 1SS133 1 223163T
D6005 DIODE 1SS133 1 223163T
D6006 DIODE 1SS133 1 223163T
D6701 C-DIODE 1SS352 1 223234R2
