Onkyo HT-RC660(B) User Manual

Step-5
18. Audio output OK/NG 19. Details of input format 20. Details of the format for the FL display
Step-6
21. Dialog norm
22. Return value of DIRINT Request_dir
(DDC_STATUS)
25. HDDVD/BLUE(only DDPLUS)
24. emphasis of information
23. Return value of DIR busy or free
Request_dir (DDC_BUSY)
Dialog Norm value from 0 to 31
2
:
18
:
19 19 19 19
:
20 20 20 20
o
decode OK
x decode NG
ANA C_SRC_ANA
PCM C_SRC_PCM
DLB C_SRC_DD
DEX C_SRC_DD_EX
DTS C_SRC_DTS
MTR C_SRC_DTS_MTR
DSC C_SRC_DTS_DSC
D96 C_SRC_DTS_96
96M C_SRC_DTS_96M
AAC C_SRC_AAC
MCH C_SRC_MCH
DSP C_SRC_DSP
MPCM C_SRC_MCHPCM
DSD C_SRC_DSD
TRUE C_SRC_TRUE
TREX C_SRC_TRUE_EX
MSTR C_SRC_MSTR
PLUS C_SRC_DDPLUS
PLEX C_SRC_DDPLUS_EX
EXP C_SRC_DTSEXP
DTSH C_SRC_DTSHD
DSUR C_SRC_DD_SUR
DPSR C_SRC_DDPLUS_SUR
TRSR C_SRC_TRUE_SUR
ANA C_SRC_ANA
PCM C_SRC_PCM
DLB C_SRC_DD
DEX C_SRC_DD_EX
DTS C_SRC_DTS
MTR C_SRC_DTS_MTR
DSC C_SRC_DTS_DSC
D96 C_SRC_DTS_96
96M C_SRC_DTS_96M
AAC C_SRC_AAC
MCH C_SRC_MCH
DSP C_SRC_DSP
MPCM C_SRC_MCHPCM
DSD C_SRC_DSD
TRUE C_SRC_TRUE
TREX C_SRC_TRUE_EX
MSTR C_SRC_MSTR
PLUS C_SRC_DDPLUS
PLEX C_SRC_DDPLUS_EX
EXP C_SRC_DTSEXP
DTSH C_SRC_DTSHD
DSUR C_SRC_DD_SUR
DPSR C_SRC_DDPLUS_SUR
TRSR C_SRC_TRUE_SUR
21 21
:
22
:
23
:
24 24 24 25 25
o
LOCK
x UNLOCK
F
Free
B Busy
ON ON
OFF OFF
BD Bluray
HD HDDVD
TX-NR535/636/737/838/DTR-30.6/40.6/50.6/HT-R593/693/993/HT-RC660
DEBUG MODE-4
AUDIO DEBUG MODE-4/5
