PC BOARD PARTS LIST
U001 BAAF-1511-1C : NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
1
D4173 ZENER DIODE DZ2J068M0L 1 224760680R2
1
D4173 or ZENER DIODE UDZS6.8B ( 1) 224550680R2
1
D4174 ZENER DIODE DZ2J068M0L 1 224760680R2
1
D4174 or ZENER DIODE UDZS6.8B ( 1) 224550680R2
1
D4206 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D4206 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D4216 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D4216 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D4300 DIODE RL1N4003 1 22380260T
1
D4301 DIODE RL1N4003 1 22380260T
1
D4302 DIODE RL1N4003 1 22380260T
1
D4303 DIODE RL1N4003 1 22380260T
1
D4304 DIODE RL1N4003 1 22380260T
1
D4305 DIODE RL1N4003 1 22380260T
1
D4309 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D4309 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D4319 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D4319 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D4500 ZENER DIODE DZ2J075M0L 1 224760750R2
1
D4500 or ZENER DIODE UDZS7.5B ( 1) 224550750R2
1
D4501 ZENER DIODE DZ2J075M0L 1 224760750R2
1
D4501 or ZENER DIODE UDZS7.5B ( 1) 224550750R2
1
D6000 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6000 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6001 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6001 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6002 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6002 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6003 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6003 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6004 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6004 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6005 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6005 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6006 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6006 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
D6401 DIODE TS10B06G-07 1 22380379
1
D6401B SCREW 3P+10FN(3BC) 1 82143010GR
1
D6402 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6402 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6451 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6451 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6452 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6452 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6455 ZENER DIODE DZ2J033M0L 1 224760330R2
1
D6455 or ZENER DIODE UDZS3.3B ( 1) 224550330R2
1
Q4001 HYBRID IC R2A15218FP 1 22242605R3
1
Q4003 HYBRID IC NJM4580M-D 1 22241448R2
1
Q4100 TRANSISTOR RTAN430C-T112-1 1 2217780R2
1
Q4100 or TRANSISTOR RN1441 ( 1) 2215410R2
1
Q4101 TRANSISTOR RTAN430C-T112-1 1 2217780R2
1
Q4101 or TRANSISTOR RN1441 ( 1) 2215410R2
1
Q4102 TRANSISTOR RTAN430C-T112-1 1 2217780R2
1
Q4102 or TRANSISTOR RN1441 ( 1) 2215410R2
1
Q4103 TRANSISTOR RTAN430C-T112-1 1 2217780R2
1
Q4103 or TRANSISTOR RN1441 ( 1) 2215410R2
1
Q4104 TRANSISTOR RTAN430C-T112-1 1 2217780R2
1
Q4104 or TRANSISTOR RN1441 ( 1) 2215410R2
1
Q4105 TRANSISTOR RTAN430C-T112-1 1 2217780R2
1
Q4105 or TRANSISTOR RN1441 ( 1) 2215410R2
