1
R5395 CHIP TYPE CARBON RESISTOR RN72K1J-121JE 1 435031214R1
1
R5396 CHIP TYPE CARBON RESISTOR RN72K1J-121JE 1 435031214R1
R5420 NON-FLAMMABLE CARBON FILM RESISTOR R25J-10 1 415471004T
R5421 NON-FLAMMABLE CARBON FILM RESISTOR R25J-10 1 415471004T
R5422 NON-FLAMMABLE CARBON FILM RESISTOR R25J-10 1 415471004T
1
R5440 TRIMMER RESISTOR N06HR1KBB 1 5211401T
1
R5441 TRIMMER RESISTOR N06HR1KBB 1 5211401T
1
R5442 TRIMMER RESISTOR N06HR1KBB 1 5211401T
1
R5443 TRIMMER RESISTOR N06HR1KBB 1 5211401T
1
R5444 TRIMMER RESISTOR N06HR1KBB 1 5211401T
1
R5445 TRIMMER RESISTOR N06HR1KBB 1 5211401T
1
R5446 TRIMMER RESISTOR N06HR1KBB 1 5211401T
1
R5450 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 1 435032224R1
1
R5451 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 1 435032224R1
1
R5452 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 1 435032224R1
R5470 NON-FLAMMABLE CARBON FILM RESISTOR R25J-82 1 415478204T
R5471 NON-FLAMMABLE CARBON FILM RESISTOR R25J-82 1 415478204T
R5472 NON-FLAMMABLE CARBON FILM RESISTOR R25J-82 1 415478204T
1
R5480 CHIP TYPE CARBON RESISTOR RN72K2E-100JE 1 435221004R1
1
R5481 CHIP TYPE CARBON RESISTOR RN72K2E-100JE 1 435221004R1
1
R5482 CHIP TYPE CARBON RESISTOR RN72K2E-100JE 1 435221004R1
1
R5490 CHIP TYPE CARBON RESISTOR RN72K2E-100JE 1 435221004R1
1
R5491 CHIP TYPE CARBON RESISTOR RN72K2E-100JE 1 435221004R1
1
R5492 CHIP TYPE CARBON RESISTOR RN72K2E-100JE 1 435221004R1
R6023 NON-FLAMMABLE CARBON FILM RESISTOR R25J-2.2 1 415470224T
R6024 NON-FLAMMABLE CARBON FILM RESISTOR R25J-2.2 1 415470224T
R6025 NON-FLAMMABLE CARBON FILM RESISTOR R25J-2.2 1 415470224T
R6026 NON-FLAMMABLE CARBON FILM RESISTOR R25J-2.2 1 415470224T
1
R6053 CHIP TYPE CARBON RESISTOR RN72K1J-332JE 1 435033324R1
1
R6054 CHIP TYPE CARBON RESISTOR RN72K1J-332JE 1 435033324R1
1
R6055 CHIP TYPE CARBON RESISTOR RN72K1J-332JE 1 435033324R1
1
R6056 CHIP TYPE CARBON RESISTOR RN72K1J-332JE 1 435033324R1
R6073 NON-FLAMMABLE CARBON FILM RESISTOR R25J-120 1 415471214T
R6074 NON-FLAMMABLE CARBON FILM RESISTOR R25J-120 1 415471214T
R6075 NON-FLAMMABLE CARBON FILM RESISTOR R25J-120 1 415471214T
R6076 NON-FLAMMABLE CARBON FILM RESISTOR R25J-120 1 415471214T
[SW TRM]
1
P5509B TERMINAL NTM-1P233(M1969) 1 25060302
P6000A SOCKET NSCT-9P2189 1 25052292
P6001A SOCKET NSCT-9P2189 1 25052292
P6002A SOCKET NSCT-9P2189 1 25052292
P6003A SOCKET NSCT-9P2189 1 25052292
P6004A SOCKET NSCT-9P2189 1 25052292
P6005A SOCKET NSCT-9P2189 1 25052292
P6006A SOCKET NSCT-9P2189 1 25052292
U004 BADIS-1530-1A : NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
1
D1000 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D1000 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D1001 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D1001 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
D1011 PHOTO COUPLER JSR1165-001recieving 1 24120143
1
D7502 ZENER DIODE DZ2J082M0L 1 224760820R2
1
D7502 or ZENER DIODE UDZS8.2B ( 1) 224550820R2
1
D7533 ZENER DIODE DZ2J039M0L 1 224760390R2
1
D7533 or ZENER DIODE UDZS3.9B ( 1) 224550390R2
D7652 LED SLI-343Y8C-3F 1 225491
D7653 LED LW340A 1 225517
D7654 LED SCB3318E-D2 1 225487
1
D7654A HOLDER (LED)LH-5-5 1 27191312
D7655 LED SCB3318E-D2 1 225487
