S7631 PUSH SWITCH NPS-111-S681 1 25035718T
1
S7632 PUSH SWITCH NPS-111-S681 1 25035718T
1
S7636 PUSH SWITCH NPS-111-S681 1 25035718T
1
S7637 PUSH SWITCH NPS-111-S681 1 25035718T
1
S7638 PUSH SWITCH NPS-111-S681 1 25035718T
U005 BATRM-1568-1A : NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D201 DIODE G10XB80-02-54A-T 1 22380378
D201 or DIODE D5SBA60 ( 1) 22380070
1
D202 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D202 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D203 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D203 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D204 ZENER DIODE DZ2J062M0L 1 224760620R2
1
D204 or ZENER DIODE UDZS6.2B ( 1) 224550620R2
1
D2101 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D2101 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D2102 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D2102 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6600 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6600 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6601 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6604 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6604 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6606 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6606 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
Q2001 HYBRID IC NJW1328 1 22242691R3
1
Q6600 TRANSISTOR KRC105S 1 2217290R2
1
Q6600 or TRANSISTOR RN1405 ( 1) 2214500R2
1
Q6601 TRANSISTOR KRC105S 1 2217290R2
1
Q6601 or TRANSISTOR RN1405 ( 1) 2214500R2
1
Q6604 TRANSISTOR KRC105S 1 2217290R2
1
Q6604 or TRANSISTOR RN1405 ( 1) 2214500R2
1
Q6606 TRANSISTOR KRC105S 1 2217290R2
1
Q6606 or TRANSISTOR RN1405 ( 1) 2214500R2
[CHASSIS SCREW]
1
D201C SCREW 3P+10FN(3BC) 1 82143010GR
[CAPACITOR]
1
C2000 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C2001 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C2004 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C2008 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C2009 CHIP TYPE CERAMIC CAPACITOR CK725F1A-105Z1 1 332181050R1
C201 ELECTROLYTIC CAPACITOR CE69W25V-10000M 1 3504512
C201 or ELECTROLYTIC CAPACITOR CE69W25V-10000M ( 1) 3504502
1
C2010 CHIP TYPE CERAMIC CAPACITOR CK725F1A-105Z1 1 332181050R1
1
C2012 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C2013 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C2014 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C2015 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
C202 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W50V-4.7M 1 398580477T
C202 or VR TYPE ELECTROLYTIC CAPACITOR CE04W50V-4.7M(VR) ( 1) 394680477T
1
C203 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-334J 1 374723344T
C207 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W6.3V-470M 1 398524717T
C207 or VR TYPE ELECTROLYTIC CAPACITOR CE04W6.3V-470M(VR) ( 1) 394624717T
1
C208 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
C2101 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W50V-2.2M 1 398580227T
C2101 or VR TYPE ELECTROLYTIC CAPACITOR CE04W50V-2.2M(VR) ( 1) 394680227T
C2102 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W50V-2.2M 1 398580227T
C2102 or VR TYPE ELECTROLYTIC CAPACITOR CE04W50V-2.2M(VR) ( 1) 394680227T
C2103 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W50V-2.2M 1 398580227T
