❏ Dolby Enabled Speakers (Dolby Speakers)
Installation Example
a
5
12
34
6
a: 22° to 30°
Separately sold Dolby-enabled speakers have been selected as the height
speakers for this system. Dolby enabled speakers are special speakers designed
to face the ceiling, so that the sound is heard from overhead by bouncing the
sound o the ceiling.
Place Dolby enabled speakers (front) above the front speakers. The front
speakers included with this unit are not designed for Dolby enabled speakers to
be installed on top of them, so do not use them with this system. Be sure to use
sold separately front speakers.
1,2 Front Speakers*
3,4 Dolby Enabled Speakers (Front)*
5 Center Speaker
6 Subwoofer
* Optional items
❏ Speaker Layouts and Selectable Listening
Modes ( p54)
