Onkyo M-5000R Instruction Manual

23
En
Specifications
■ Audio Inputs
■ Audio Outputs
■ Others
Specifications and features are subject to change without notice.
M-5000R
Amplifier Section
Rated Output Power
North American:
(Stereo) 80 watts minimum continuous power per
channel, 8 ohm loads, 2 channels driven from
20 Hz to 20 kHz, with a maximum total
harmonic distortion of 0.05% (FTC)
100 watts minimum continuous power per
channel, 8 ohm loads, 2 channels driven at
1 kHz, with a maximum total harmonic
distortion of 1% (FTC)
150 watts minimum continuous power per
channel, 4 ohm loads, 2 channels driven from
20 Hz to 20 kHz, with a maximum total
harmonic distortion of 0.05% (FTC)
170 watts minimum continuous power per
channel, 4 ohm loads, 2 channels driven at 1 kHz,
with a maximum total harmonic distortion of
1% (FTC)
(BTL mono) 180 watts minimum continuous power per
channel, 8 ohm loads, 1 channel driven from
20 Hz to 20 kHz, with a maximum total
harmonic distortion of 0.05% (FTC)
200 watts minimum continuous power per
channel, 8 ohm loads, 1 channel driven at 1 kHz,
with a maximum total harmonic distortion of
1% (FTC)
220 watts minimum continuous power per
channel, 6 ohm loads, 1 channel driven from
20 Hz to 20 kHz, with a maximum total
harmonic distortion of 0.05% (FTC)
250 watts minimum continuous power per
channel, 6 ohm loads, 1 channel driven at 1 kHz,
with a maximum total harmonic distortion of
1% (FTC)
European:
(Stereo)
2 ch × 80 W at 8 ohms, 20 Hz - 20 kHz, 0.05 %,
2 ch driven (IEC)
2 ch
× 150 W at 4 ohms, 20 Hz - 20 kHz, 0.05 %,
2 ch driven (IEC)
2 ch
× 100 W at 8 ohms, 1 kHz, 1 %, 2 ch driven
(IEC)
2 ch
× 170 W at 4 ohms, 1 kHz, 1 %, 2 ch driven
(IEC)
(BTL mono)
1ch × 180 W at 8 ohms, 20 Hz - 20 kHz, 0.05 %,
1 ch driven (IEC)
1ch
× 220 W at 6 ohms, 20 Hz - 20 kHz, 0.05 %,
1 ch driven (IEC)
1ch × 200 W at 8 ohms, 1 kHz, 1 %, 1 ch driven
(IEC)
1ch
× 250 W at 6 ohms, 1 kHz, 1 %, 1 ch driven
(IEC)
Dynamic Power
*
*
IEC60268-Short-term maximum output power
460 W (1 Ω)
320 W (2 Ω)
245 W (3 Ω)
196 W (4 Ω)
142 W (6 Ω)
110 W (8 Ω)
THD+N (Total Harmonic Distortion+Noise) 0.02 % (20 Hz - 20 kHz, half power)
0.005 % (1 kHz, half power)
Damping Factor 130 (1 kHz, 8 Ω)
Input Sensitivity and Impedance (Unbalance) 700 mV/10 kΩ (RCA)
Input Sensitivity and Impedance (Balance) 1.4 V/10 kΩ (BTL)
Frequency Response 10 Hz - 100 kHz/+0 dB, –1 dB 1 W/8 Ω
1 Hz - 250 kHz/+0 dB, –3 dB 1 W/8 Ω
Signal to Noise Ratio 110 dB (RCA, IHF-A)
Speaker Impedance RCA Stereo: 4 Ω - 16 Ω
XLR MONO: BTL 6 Ω - 16 Ω
HICC 150 A
General Section
Power Supply North American: AC 120 V, 60 Hz
European: AC 230 V, 50 Hz
Power Consumption North American: 8.4 A
European: 280 W
Standby Power Consumption North American: 0.15 W
European: 0.2 W
Dimensions (W × H × D) 435 W × 187.5 H × 432.5 D mm
(17-1/8 W × 7-3/8 H × 17 D inches)
Weight 23.5 kg (51.8 lbs.)
Analog Stereo Inputs RCA IN-L, RCA IN-R
Balance Inputs XLR IN
Speaker Outputs Lch, Rch
12V Trigger In 1/Out 1

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
