Onkyo M-5000R Service Manual

1/37 PAGE
M-5000R
<Note>
Parts marked by "NSP" are generally unavailable because <Notes>
they are not in our Master Spare Parts List.
(B) : Black model
(S) : Silver model
<MDC> : 120V,Canadian model
<MPP> : 230V,CE(European) country model
<MJJ> : 100V, Japanese model
M-5000R
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D9501 BRIDGE DIODE BR64 1 22380369
N
D9502 BRIDGE DIODE BR64 1 22380369
N
D9503 BRIDGE DIODE BR64 1 22380369
N
D9504 BRIDGE DIODE BR64 1 22380369
N
Q6503 TR 2SC3423-Y 1 2202104
Q6504 TR 2SC3423-Y 1 2202104
Q6511 TR 2SA1930(ONK_Q) 1 2203000
Q6512 TR 2SA1930(ONK_Q) 1 2203000
Q6513 TR 2SC5171(ONK_Q) 1 2203010
Q6514 TR 2SC5171(ONK_Q) 1 2203010
Q6515 TR 2SC3423-Y 1 2202104
Q6516 TR 2SC3423-Y 1 2202104
Q6517 TR 2SA1360-Y 1 2202094
Q6518 TR 2SA1360-Y 1 2202094
Q6519 TR 2SC3423-Y 1 2202104
Q6520 TR 2SC3423-Y 1 2202104
Q6521 TR TTC0002(Q)TO3PL 1 2204150
Q6521A ISO SHEET TO-3PL BFG20 1 223059
N
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
