Onkyo M-5000R Service Manual

2/37 PAGE
Q6522 TR TTC0002(Q)TO3PL 1 2204150
Q6522A ISO SHEET TO-3PL BFG20 1 223059
N
Q6523 TR TTC0002(Q)TO3PL 1 2204150
Q6523A ISO SHEET TO-3PL BFG20 1 223059
N
Q6524 TR TTC0002(Q)TO3PL 1 2204150
Q6524A ISO SHEET TO-3PL BFG20 1 223059
N
Q6525 TR TTC0002(Q)TO3PL 1 2204150
Q6525A ISO SHEET TO-3PL BFG20 1 223059
N
Q6526 TR TTC0002(Q)TO3PL 1 2204150
Q6526A ISO SHEET TO-3PL BFG20 1 223059
N
Q6527 TR TTC0002(Q)TO3PL 1 2204150
Q6527A ISO SHEET TO-3PL BFG20 1 223059
N
Q6528 TR TTC0002(Q)TO3PL 1 2204150
Q6528A ISO SHEET TO-3PL BFG20 1 223059
N
Q6529 TR TTA0002(Q)TO3PL 1 2204140
Q6529A ISO SHEET TO-3PL BFG20 1 223059
N
Q6530 TR TTA0002(Q)TO3PL 1 2204140
Q6530A ISO SHEET TO-3PL BFG20 1 223059
N
Q6531 TR TTA0002(Q)TO3PL 1 2204140
Q6531A ISO SHEET TO-3PL BFG20 1 223059
N
Q6532 TR TTA0002(Q)TO3PL 1 2204140
Q6532A ISO SHEET TO-3PL BFG20 1 223059
N
Q6533 TR TTA0002(Q)TO3PL 1 2204140
Q6533A ISO SHEET TO-3PL BFG20 1 223059
N
Q6534 TR TTA0002(Q)TO3PL 1 2204140
Q6534A ISO SHEET TO-3PL BFG20 1 223059
N
Q6535 TR TTA0002(Q)TO3PL 1 2204140
Q6535A ISO SHEET TO-3PL BFG20 1 223059
N
Q6536 TR TTA0002(Q)TO3PL 1 2204140
Q6536A ISO SHEET TO-3PL BFG20 1 223059
N
[CHASSIS SCREW]
A001 SIDE PANEL (L)(S) 1 28185484C
N
<S>
A001 SIDE PANEL (L)(B) 1 28185490C
N
<B>

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
