Onkyo M-5000R Service Manual

3/37 PAGE
A003 SIDE PANEL (R)(S) 1 28185485C
N
<S>
A003 SIDE PANEL (R)(B) 1 28185491C
N
<B>
A004 REAR PANEL MPP 1 27124201D
N
<B MPP / S MPP>
A004 REAR PANEL MJJ 1 27124202D
N
<S MJJ>
A004 REAR PANEL MDC 1 27124217D
N
<B MDC>
A005 BRACKET (F) 1 27131090C
N
A006 HOLDER KGLS-3S 8 27190897
A007 F PANEL (S) 1 27213409D
N
<S MJJ, MPP>
A007 F PANEL (B) 1 27213416D
N
<B MDC, MPP>
A008 BUSHING L125 1 28170004
A009 HOLDER HOLDER KGLS-18S 2 27190470
A015 STAY (BASE) 2 28183006
A016 STAY (U1) 1 28183007
A017 STAY (U2) 2 28183014
A018 SPACER (PC) 16 27270531
A019 SPACER (PC) 8 27270534
A020 HEAT SINK (M) 2 27160652A
N
A028 CLAMP HL-28-0 2 27301396
A031 RETAINER (METER-L) 2 27142244
N
A032 RETAINER (METER-R) 2 27142245
N
A033 BRACKET (PT) 1 27131094A
N
A034 HOLDER (CH) 2 27191349
A035 BRACKET (CH) 1 27131104A
N
A036 PLATE (LED) 2 27262858
A037 BOTTOM BRD --- 1 27170337A
N
A038 LEG --- 4 27175465
N
A040 CUSHION T0.8*Φ29*10 4 28141853A
A041 RETAINER (BUS-C) 2 27142204A
N
A042 RETAINER (BUS-CFL) 1 27142209A
N
A043 RETAINER (BUS-CFR) 1 27142210A
N
A044 RETAINER (BUS-CBL) 1 27142211A
N
A045 RETAINER (BUS-CBR) 1 27142212A
N
A050 HEAT SINK (5). 2 27160659A
N

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
