Onkyo M-5000R Service Manual

4/37 PAGE
A052 HOLDER (CLAMP) WS-1NS 2 27190541
A053 HOLDER WS-4NS 1 27191207
A054 PLATE (TR) 8 27262865
N
A057 LABEL (FLASH)(B) 2 29391423 <B MDC>
A059 RETAINER (HL) 1 27142228
N
A060 RETAINER (HR) 1 27142229
N
A067 SPACER
t0.5xφ8xφ3.2 Teflon‐lined.
2 27270438
A137 ISO PLATE (ST) 1 28175344
N
A320 TUBE (SPIRAL) 1 262093
A012 SCREW 3B+6BN. 14 82563006
A026 SCREW 3P+10FN(3BC) 12 82143010GR
A022 SCREW 3P+6FN(3BC) 16 82143006GR
A023 SCREW 3P+6FN(3BC) 8 82143006GR
A064 SCREW 3SMS8W.SW+14B(3BC) 10 801433GR
A021 SCREW 3SMS8W.SW+14B(CU) 16 801634
A062 SCREW 3TTB+10B(3BC) 4 838430108GR
A004 SCREW 3TTB+8B(3BC) 18 838430088GR
A027 SCREW 3TTB+8B(3BC) 11 838430088GR
A030 SCREW 3TTB+8B(3BC) 18 838430088GR
A061 SCREW 3TTB+8B(3BC) 2 838430088GR
A014 SCREW 3TTF+10B(3BC) 2 835430108GR
A011 SCREW 4B+6BN. 8 82564006
A039 SCREW 4TTB+20C(3BC) 4 838404209
A029 SCREW 4TTB+8C(3BC) 12 838440089GR
A010 SCREW 4TTC+8C(3BC) 30 830440089GR
[CABINET]
A065 CUSHION T10*90*55HBK 2 28141862
N
A069 WASHER W3*8F(3CM) 4 87613008GR
A101 HOLDER (METER) 1 27191350A
N
A102 GUIDE (STANDBY) 1 27268263A
A103 GUIDE (A) 1 27268264A
A104 FACET (STBY) 1 28200052
A106 KNOB (STBY)S 1 28326863A <S>

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
