Onkyo M-5000R Service Manual

5/37 PAGE
A106 KNOB (STBY)B 1 28326864A <B>
A107 KNOB (A)S 1 28326865A <S>
A107 KNOB (A)B 1 28326866A <B>
A108 KNOB (POW)AS(S) 1 28326899B <S>
A108 KNOB (POW)AS(B) 1 28326900B <B>
A109 KNOB (STANDBY-POW) 1 28326862B
N
A110 CUSHION --- 2 28141854
A115 CLEAR PLT --- 1 28192323B
A116 CLEAR PLT (B) 1 28192327B
A117 BADGE (NI) 1 28135318 <S>
A118 BADGE (NI) 1 28135318 <B>
A120 COVER (S) 1 28210074B
N
<S>
A121 COVER (B) 1 28210077B
N
<B>
A122 COVER (PM)(S) 2 28210078A
N
<S>
A123 COVER (PM)(B) 2 28210079A
N
<B>
A127 CUSHION T0.7*60*4 24 28141860
N
A128 CUSHION T0.7*110*4 4 28141861
N
A130 TAPE (CU)10*220 2 29110212
N
A131 FILM 10*30 1 28199230
N
A116
A132 FILM 12*27 2 28199231
N
A036
A133 FILM 12*50 2 28199232
N
A135 SPACER φ6*φ3.9*t0.5 1 27270541
N
A100 SCREW 3P+10FN(3BC) 2 82143010GR
A111 SCREW 3P+6FN(3BC) 18 82143006GR
A124 SCREW 2.6P+3F(BC) 22 82142603
A125 SCREW (COVER) 8 801645 <S>
A125 SCREW (COVER) 8 801657 <B>
A208 LABEL (PT) 2 29391612
N
A211 LABEL (CAUTION) 1 29363797 <S>
A211 LABEL (COVER) 1 29364123 <B>
[TRANS COIL]
T9501 P TRANS NPT-1599J 1 2302002
N, !
<S MJJ>
T9501 P TRANS NPT-1599D 1 2302003
!
<B MDC>

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
