Onkyo M-5000R Service Manual

6/37 PAGE
T9501 P TRANS NPT-1599P 1 2302004
!
<B MPP / S MPP>
T9502 P TRANS NPT-1599J 1 2302002
N, !
<S MJJ>
T9502 P TRANS NPT-1599D 1 2302003
!
<B MDC>
T9502 P TRANS NPT-1599P 1 2302004
!
<B MPP / S MPP>
T9503 P TRANS NPT-1600JQ 1 2302005
!
[CAPACITOR]
C9501 ELECT C CE62W56V-27000M 1 3504475
C9502 ELECT C CE62W56V-27000M 1 3504475
C9503 ELECT C CE62W56V-27000M 1 3504475
C9504 ELECT C CE62W56V-27000M 1 3504475
[SW TRM]
F9501 FUSE 1.6A-SE-EAK IECFUSE 1 252073GR
!
<B MPP / S MPP>
F9501 FUSE 5A-UL/T-233 1 252326GR
!
<B MDC / S MJJ>
F9501A FUSE LABEL T5AL125V 1 29391563
N, !
<B MDC / S MJJ>
F9502 FUSE 1.6A-SE-EAK IECFUSE 1 252073GR
!
<B MPP / S MPP>
F9502 FUSE 5A-UL/T-233 1 252326GR
!
<B MDC / S MJJ>
F9502A FUSE LABEL T5AL125V 1 29391563
N, !
<B MDC / S MJJ>
F9503 FUSE 2.5A-SE-EAK FUSE 1 252075GR
!
<B MPP / S MPP>
F9503 FUSE 5A-UL/T-233 1 252326GR
!
<B MDC / S MJJ>
F9503A FUSE LABEL T5AL125V 1 29391563
N, !
<B MDC / S MJJ>
F9504 FUSE 2.5A-SE-EAK FUSE 1 252075GR
!
<B MPP / S MPP>
F9504 FUSE 5A-UL/T-233 1 252326GR
!
<B MDC / S MJJ>
F9504A FUSE LABEL T5AL125V 1 29391563
N, !
<B MDC / S MJJ>
P6503B TRM NTM-2PMCRW431T01-430-01 1 25060505
N
P6503C CRIMP AS SP WIRING 1 20799185UL
P6504B TRM NTM-2PMCRW431T01-430-01 1 25060505
N
P6504C CRIMP AS SP WIRING 1 20799185UL
P9801 P RIVET SP RIVET 4 880055 <B MPP / S MPP>
P9506B AC INLET R301X2PSn 1 25053358
!
<B MDC, MPP / S MPP>
P9506B AC INLET R301X3PSn 1 25053359
!
<S MJJ>
P9506C FASTON AS FASTON SOCKET 1 1F999027
P9537 RETAINER (BUS-AMP2) 1 27142214
P9538 RETAINER (BUS-AMP2) 1 27142214

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
