Onkyo M-5000R Service Manual

7/37 PAGE
Q7703 METER NIND-1200S175 1 243175A
N
Q7704 METER NIND-1200S175 1 243175A
N
R7771A FUSE LABEL 0.5A/125V 1 29391617
R7772A FUSE LABEL 0.5A/125V 1 29391617 NO NEED BAPS-0559 VER.B.
R9709A FUSE LABEL 0.5A/125V 1 29391617 NO NEED BAPS-0559 VER.B.
[TUNER UNIT]
U001 U0010 ~ U00110 BAAMP-0549-1A * 1 1B255549-1A
U0010 Power Amplifier (Lch) Circuit pc board a'
s
BAAMP-0549-1A 1 1B2555549-1A
U0011 Power Amplifier (Rch) Circuit pc board a'
s
BAAMP-0550-1A 1 1B2555550-1A
N
U0012 Meter-S (Lch) Circuit pc board a'ssy BAETC-0555-1A 1 1B2555555-1A
N
U0013 Meter-S (Rch) Circuit pc board a'ssy BAETC-0556-1A 1 1B2555556-1A
N
U0014 Light (Lch) Circuit pc board a'ssy BAETC-0612-1A 1 1B2555612-1A
N
U0015 Light (Rch) Circuit pc board a'ssy BAETC-0613-1A 1 1B2555613-1A
N
U0016 Bridge Diode (D9501) Circuit pc board a'
s
BAETC-0941-1A 1 1B2555941-1A
N
U0017 Bridge Diode (D9502) Circuit pc board a'
s
BAETC-0942-1A 1 1B2555942-1A
N
U0018 Bridge Diode (D9503) Circuit pc board a'
s
BAETC-0943-1A 1 1B2555943-1A
N
U0019 Bridge Diode (D9504) Circuit pc board a'
s
BAETC-0944-1A 1 1B2555944-1A
N
U00110 Hold AC Power Switch pc board a'ssy BAETC-0837-1A 1 1B2555837-1A
N
U002 U0020 ~ U0026 BAPS-0559-1A * 1 1B255559-1A N <S MJJ>
U0020 Power Supply Circuit pc board a'ssy BAPS-0559-1A 1 1B2555559-1A
N
<S MJJ>
U0021 AC Power Switch Circuit pc board a'ssy BASW-0558-1A 1 1B2555558-1A
N
<S MJJ>
U0022 Relay Circuit pc board a'ssy BAETC-0560-1A 1 1B2555560-1A
N
<S MJJ>
U0023 Meter Circuit pc board a'ssy BAETC-0562-1A 1 1B2555562-1A
N
<S MJJ>
U0024 Display Switch Circuit pc board a'ssy BADIS-0563-1A 1 1B2555563-1A
N
<S MJJ>
U0025 Meter Range LED Circuit pc board a'ssy BAETC-0554-1A 1 1B2555554-1A
N
<S MJJ>
U0026 RCA Input Circuit pc board a'ssy BATRM-0552-1A 1 1B2555552-1A
N
<S MJJ>
U002 U0020 ~ U0026 BAPS-0559-1B * 1 1B255559-1B <B MPP / S MPP>
U0020 Power Supply Circuit pc board a'ssy BAPS-0559-1B 1 1B2555559-1B <B MPP / S MPP>
U0021 AC Power Switch Circuit pc board a'ssy BASW-0558-1B 1 1B2555558-1B
N
<B MPP / S MPP>
U0022 Relay Circuit pc board a'ssy BAETC-0560-1B 1 1B2555560-1B
N
<B MPP / S MPP>
U0023 Meter Circuit pc board a'ssy BAETC-0562-1B 1 1B2555562-1B
N
<B MPP / S MPP>
U0024 Display Switch Circuit pc board a'ssy BADIS-0563-1B 1 1B2555563-1B
N
<B MPP / S MPP>
U0025 Meter Range LED Circuit pc board a'ssy BAETC-0554-1B 1 1B2555554-1B
N
<B MPP / S MPP>

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
