Onkyo M-5000R Service Manual

8/37 PAGE
U0026 RCA Input Circuit pc board a'ssy BATRM-0552-1B 1 1B2555552-1B
N
<B MPP / S MPP>
U002 U0020 ~ U0026 BAPS-0559-1C * 1 1B255559-1C <B MDC>
U0020 Power Supply Circuit pc board a'ssy BAPS-0559-1C 1 1B2555559-1C <B MDC>
U0021 AC Power Switch Circuit pc board a'ssy BASW-0558-1C 1 1B2555558-1C
N
<B MDC>
U0022 Relay Circuit pc board a'ssy BAETC-0560-1C 1 1B2555560-1C
N
<B MDC>
U0023 Meter Circuit pc board a'ssy BAETC-0562-1C 1 1B2555562-1C
N
<B MDC>
U0024 Display Switch Circuit pc board a'ssy BADIS-0563-1C 1 1B2555563-1C
N
<B MDC>
U0025 Meter Range LED Circuit pc board a'ssy BAETC-0554-1C 1 1B2555554-1C
N
<B MDC>
U0026 RCA Input Circuit pc board a'ssy BATRM-0552-1C 1 1B2555552-1C
N
<B MDC>
U003 U0030 ~ U0034 BACLA-0564-1A * 1 1B255564-1A
U0030 Preamplifier 1st (Lch) circuit pc board a's
s
BACLA-0564-1A 1 1B2555564-1A
U0031 Preamplifier 1st (Rch) circuit pc board a's
s
BACLA-0565-1A 1 1B2555565-1A
N
U0032 Preamplifier 2nd (Lch) circuit pc board a'
s
BACLA-0604-1A 1 1B2555604-1A
N
U0033 Preamplifier 2nd (Rch) circuit pc board a'
s
BACLA-0605-1A 1 1B2555605-1A
N
U0034 Main Microprocessor circuit pc board a'ss
y
BADG-0566-1A 1 1B2555566-1A
N
M-5000R
PACKING PROCEDURES PARTS LIS
T
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[PACKING]
A036 CARTON --- 1 29055175A
N
<B MDC, MPP / S MPP>
A036 CARTON (S)MJJ 1 29055188A
N
<S MJJ>
A037A JAN LABEL M-5000R(S)MJJ { 1} 29391375
N
<S MJJ>
A037A UPC LABEL M-5000R(B)MDC { 1} 29391379
N
<B MDC>
A037A EAN LABEL M-5000R(S)MPP { 1} 29391382
N
<S MPP>
A037A EAN LABEL M-5000R(B)MPP { 1} 29391383
N
<B MPP>
A201 PAD AS 1 29092547A
N
A202 SHEET T0.515*1300*900 1 29096066
A203 TAPE (SEROHAN)NITTO NO.29 1 29110149
A204 PP TAPE W50 SBT-70 1 29110200
A204 or PP TAPE NITTO No.3903(50mmx100m) ( 1) 29110205

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
