Onkyo M-5000R Service Manual

9/37 PAGE
A205 POLY BAG w250xd350 1 29100250A
A206 TAPE (SEROHAN)NITTO NO.29 1 29110149
A207 SHEET (ACC)A4 1 29096115A
A209 STAPLE FUKAN-BARI(1000KO) 4 282321
[ACCESSARY]
A038 WRNTY CARD (ONKYO) 1 29365135 <B MDC>
A038 WRNTY CARD AS 1 29365093C <S MJJ>
A039 TAPE (SEROHAN)NITTO NO.29 1 29110149
A840 DIRECTORY --- 1 29358032C <S MJJ>
A841 QUST SHEET JJ 1 29370045D <S MJJ>
A842 INST SHEET WEEE 1 29355793 <B MPP / S MPP>
A851 INS MANUAL En(M-5000R) 1 29400545
N
<B MDC, MPP / S MPP>
A852 INS MANUAL U2FrEs(M-5000R) 1 29400546
N
<B MDC, MPP / S MPP>
A853 INS MANUAL U2ItDe(M-5000R) 1 29400547
N
<B MPP / S MPP>
A854 INS MANUAL U2NiSv(M-5000R) 1 29400548
N
<B MPP / S MPP>
A855 INS MANUAL Ja(M-5000R) 1 29400549
N
<S MJJ>
P902 CORD AS 3.5 MINI PLUG 1 2010431
A9506 POLY BAG W250 x D350 1 29100250A
P9506D AC CORD AS-CEE-3 1 253298VOL
!
<B MPP / S MPP>
P9506D AC CORD AS-UC-2 1 253301VOL
!
<B MDC>
P9506D AC CORD AS-JA 1 253382KAW
!
<S MJJ>
M-5000R
PC BOARD PARTS LIS
T
U001 AMP-AS BAAMP-0549-1 *
1
1B255549-1
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D2523 LED SLR343WBD2P_3-XR/XS_Rank 1 225499A
N
D2524 LED SLR343WBD2P_3-XR/XS_Rank 1 225499A
N
D6503 C-DIODE 1SS352 1 223234R2

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
