Onkyo M-5000R Service Manual

10/37 PAGE
D6504 C-DIODE 1SS352 1 223234R2
D6505 C-DIODE 1SS352 1 223234R2
D6506 C-DIODE 1SS352 1 223234R2
D6507 C-DIODE 1SS352 1 223234R2
D6508 C-DIODE 1SS352 1 223234R2
D6509 ZENER D UDZS4.3B 1 224550430R2
D6510 ZENER D UDZS4.3B 1 224550430R2
D6511 ZENER D UDZS5.1B 1 224550510R2
D6512 ZENER D UDZS5.1B 1 224550510R2
D6513 DIODE RL1N4003 1 22380260T
D6514 DIODE RL1N4003 1 22380260T
D6515 DIODE RL1N4003 1 22380260T
D6516 DIODE RL1N4003 1 22380260T
D6517 ZENER D MTZJ5.1B 1 224470512T
D6518 ZENER D MTZJ5.1B 1 224470512T
D6519 C-DIODE 1SS352 1 223234R2
D6520 C-DIODE 1SS352 1 223234R2
D6521 C-DIODE 1SS352 1 223234R2
D6522 C-DIODE 1SS352 1 223234R2
Q6501 TR 2SC2713-GR(TE85R_F) 1 2213135R2
Q6502 TR 2SC2713-GR(TE85R_F) 1 2213135R2
Q6537 TR 2SC2713-GR(TE85R_F) 1 2213135R2
Q6538 TR 2SC2713-GR(TE85R_F) 1 2213135R2
Q6543 TR 2SA1163-BL(TE85L_F) 1 2216756R2
Q6544 TR 2SA1163-BL(TE85L_F) 1 2216756R2
Q6545 TR 2SA1163-BL(TE85L_F) 1 2216756R2
Q6546 TR 2SA1163-BL(TE85L_F) 1 2216756R2
Q6547 TR 2SC2713-GR(TE85R_F) 1 2213135R2
Q6548 TR 2SC2713-GR(TE85R_F) 1 2213135R2
Q6549 IC TC7S14F(TE85L_F) 1 22241175R2
Q6550 IC TC7S14F(TE85L_F) 1 22241175R2
[CHASSIS SCREW]
D2523B HOLDER (LED-LH5-2) 1 27191336

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
