Onkyo M-5000R Service Manual

11/37 PAGE
D2524B HOLDER (LED-LH5-2) 1 27191336
[TRANS COIL]
L6505 S-COIL SC-1.1X6.5X26.5T 1 231433S
N
L6506 S-COIL SC-1.1X6.5X26.5T 1 231433S
N
[CAPACITOR]
C6503 MKT C B32529C0102J289 1 376491024T
C6503 or UMXR C 1HUMXRTF102JE ( 1) 376521024T
C6504 MKT C B32529C0102J289 1 376491024T
C6504 or UMXR C 1HUMXRTF102JE ( 1) 376521024T
C6505 UTSP C CE04W100V-22M(UTSP) 1 397592207T
C6506 UTSP C CE04W100V-22M(UTSP) 1 397592207T
C6509 C-CERA C CK725B1H-103K1 1 332101035R1
C6510 C-CERA C CK725B1H-103K1 1 332101035R1
C6511 TF C ECQ-V100V-333J 1 374733334T
C6512 TF C ECQ-V100V-333J 1 374733334T
C6513 UTSP C CE04W100V-22M(UTSP) 1 397592207T
C6514 UTSP C CE04W100V-22M(UTSP) 1 397592207T
C6515 UTSP C CE04W25V-100M(UTSP) 1 397551017T
C6516 UTSP C CE04W25V-100M(UTSP) 1 397551017T
C6517 C-CERA C CK725B1H-223K1 1 332102235R1
C6518 C-CERA C CK725B1H-223K1 1 332102235R1
C6519 UTSP C CE04W50V-1M(UTSP) 1 397580107T
C6520 UTSP C CE04W50V-1M(UTSP) 1 397580107T
C6521 C-CERA C CK725B1H-223K1 1 332102235R1
C6522 C-CERA C CK725B1H-223K1 1 332102235R1
C6523 UTSP C CE04W50V-4.7M(UTSP) 1 397580477T
C6524 UTSP C CE04W50V-4.7M(UTSP) 1 397580477T
C6525 UTSP C CE04W63V-100M(UTSP) 1 397571017T
C6526 UTSP C CE04W63V-100M(UTSP) 1 397571017T
C6527 UTSP C CE04W63V-100M(UTSP) 1 397571017T
C6528 UTSP C CE04W63V-100M(UTSP) 1 397571017T
C6529 TF C ECQ-V50V-104J 1 374721044T
C6530 TF C ECQ-V50V-104J 1 374721044T

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
