Onkyo M-5000R Service Manual

12/37 PAGE
C6531 UTSP C CE04W10V-100M(UTSP) 1 397531017T
C6532 UTSP C CE04W10V-100M(UTSP) 1 397531017T
C9534 TF C ECQ-V100V-334J 1 374733344T
C9535 TF C ECQ-V100V-334J 1 374733344T
C9536 TF C ECQ-V100V-334J 1 374733344T
C9537 TF C ECQ-V100V-334J 1 374733344T
[RESISTOR]
L6523 FR CORE * 1 5597-45502
L6524 FR CORE * 1 5597-45502
L6525 FR CORE * 1 5597-45502
L6526 FR CORE * 1 5597-45502
R2539 C-CARBON R RN72K1J-122JE 1 435031224R1
R2540 C-CARBON R RN72K1J-122JE 1 435031224R1
R2551 C-CARBON R RN72K1J-122JE 1 435031224R1
R2552 C-CARBON R RN72K1J-122JE 1 435031224R1
R6525 C-CARBON R RN72K1J-562JE 1 435035624R1
R6526 C-CARBON R RN72K1J-562JE 1 435035624R1
R6527 C-CARBON R RN72K1J-333JE 1 435033334R1
R6528 C-CARBON R RN72K1J-333JE 1 435033334R1
R6529 C-CARBON R RN72K1J-103JE 1 435031034R1
R6530 C-CARBON R RN72K1J-103JE 1 435031034R1
R6531 C-CARBON R RN72K1J-392JE 1 435033924R1
R6532 C-CARBON R RN72K1J-392JE 1 435033924R1
R6533 C-CARBON R RN72K1J-562JE 1 435035624R1
R6534 C-CARBON R RN72K1J-562JE 1 435035624R1
R6541 C-CARBON R RN72K1J-272JE 1 435032724R1
R6542 C-CARBON R RN72K1J-272JE 1 435032724R1
R6545 C-CARBON R RN72K1J-392JE 1 435033924R1
R6546 C-CARBON R RN72K1J-392JE 1 435033924R1
R6551 CARBON R R16J-180K 1 417341844T
R6552 CARBON R R16J-180K 1 417341844T
R6553 TRIM R N06HR2KBB 1 5211402T
R6554 TRIM R N06HR2KBB 1 5211402T

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
