Onkyo M-5000R Service Manual

31/37 PAGE
Q7516 TR KRC104S 1 2216210R2
Q7517 TR KRC104S 1 2216210R2
Q7518 TR KRC104S 1 2216210R2
Q7519 TR KRC104S 1 2216210R2
Q7520 TR KRC104S 1 2216210R2
Q7521 TR KRC104S 1 2216210R2
[CAPACITOR]
C5501 TF C ECQ-V50V-104J 1 374721044T
C5502 TF C ECQ-V50V-104J 1 374721044T
C5503 TF C ECQ-V50V-104J 1 374721044T
C5504 TF C ECQ-V50V-104J 1 374721044T
C5505 CERA C CC45CH50V-030C 1 345340301T
C5506 CERA C CC45CH50V-030C 1 345340301T
C5507 UPZ C 2AUPZTF101JE 1 376331014T
C5508 UPZ C 2AUPZTF101JE 1 376331014T
C5517 UTSJ C CE04W50V-22M(UTSJ) 1 398082207AT
C5518 UTSJ C CE04W50V-22M(UTSJ) 1 398082207AT
C5601 TF C ECQ-V50V-104J 1 374721044T
C5602 TF C ECQ-V50V-104J 1 374721044T
C5603 TF C ECQ-V50V-104J 1 374721044T
C5604 TF C ECQ-V50V-104J 1 374721044T
C5607 UPZ C 2AUPZTF151JE 1 376331514T
C5608 UPZ C 2AUPZTF151JE 1 376331514T
C5611 UTSJ C CE04W50V-22M(UTSJ) 1 398082207AT
C5612 UTSJ C CE04W50V-22M(UTSJ) 1 398082207AT
C5617 UTSJ C CE04W50V-22M(UTSJ) 1 398082207AT
C5618 UTSJ C CE04W50V-22M(UTSJ) 1 398082207AT
C7500 C-CERA C CK725F1E-104Z1 1 332161040R1
C7501 C-CERA C CK725B1H-102K1 1 332101025R1
C7502 UTSP C CE04W16V-330M(UTSP) 1 397543317T
C7503 C-CERA C CK725B1H-102K1 1 332101025R1
C7504 C-CERA C CK725F1E-104Z1 1 332161040R1
C7507 C-CERA C CK725F1E-104Z1 1 332161040R1

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
