Onkyo M-5000R Service Manual

32/37 PAGE
C7508 C-CERA C CK725F1E-104Z1 1 332161040R1
C7509 C-CERA C CK725B1H-102K1 1 332101025R1
C7510 C-CERA C CK725B1H-102K1 1 332101025R1
C7513 UTSP C CE04W50V-10M(UTSP) 1 397581007T
C7514 C-CERA C CK725F1E-104Z1 1 332161040R1
C7515 UTSP C CE04W16V-470M(UTSP) 1 397544717T
C7516 UTSP C CE04W25V-100M(UTSP) 1 397551017T
C7517 C-CERA C CK725F1E-104Z1 1 332161040R1
C7518 UTSP C CE04W16V-330M(UTSP) 1 397543317T
C7522 C-CERA C CK725F1E-104Z1 1 332161040R1
C7527 C-CERA C CK725F1E-104Z1 1 332161040R1
C7528 C-CERA C CK725F1E-104Z1 1 332161040R1
D5501 ZENER D MTZJ33B 1 224473302T
D5502 ZENER D MTZJ33B 1 224473302T
D5601 ZENER D MTZJ33B 1 224473302T
D5602 ZENER D MTZJ33B 1 224473302T
X7500 CERA LOCK CR06000-TG-A0R 1 3010433T
[RESISTOR]
R5501 CARBON R R16J-1.5K 1 417341524T
R5502 CARBON R R16J-1.5K 1 417341524T
R5503 CARBON R R16J-680 1 417346814T
R5504 CARBON R R16J-680 1 417346814T
R5505 CARBON R R16J-680 1 417346814T
R5506 CARBON R R16J-680 1 417346814T
R5511 CARBON R R16J-220 1 417342214T
R5512 CARBON R R16J-220 1 417342214T
R5513 CARBON R R16J-330 1 417343314T
R5514 CARBON R R16J-330 1 417343314T
R5515 CARBON R R16J-330 1 417343314T
R5516 CARBON R R16J-330 1 417343314T
R5517 CARBON R R16J-10K 1 417341034T
R5518 CARBON R R16J-10K 1 417341034T
R5519 CARBON R R16J-15K 1 417341534T

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
