Onkyo P-3000R Service Manual

4/55 PAGE
EV
U0013 PHONO EQ. AMP. (Lch) PC Board ass'y BAAF-0570-1B 1 1B2565570-1B
N
EV
U0014 PHONO EQ. AMP. (Rch) PC Board ass'y BAAF-0571-1B 1 1B2565571-1B
N
EV
U0015 HEADPHONE JACK PC Board ass'y BATRM-0572-1B 1 1B2565572-1B
N
EV
U0016 STANDBY SWITCH PC Board ass'y BASW-0586-1B 1 1B2565586-1B
N
EV
U0017 INPUT SELECTOR PC Board ass'y BAETC-0590-1B 1 1B2565590-1B
N
EV
U0018 TONE CONTROL PC Board ass'y BAAF-0599-1B 1 1B2565599-1B
N
EV
U002 U0020 + U0021 + U0022 + U0023 + U0024 + U0025 BADG-0573-1C * 1 1B256573-1C N <MDC>
EV
U002 U0020 + U0021 + U0022 + U0023 + U0024 + U0025 BADG-0573-1B * 1 1B256573-1B N <MPP>
EV
U0020 DIGITAL PC Board ass'y BADG-0573-1C 1 1B2565573-1C
N
<MDC>
EV
U0020 DIGITAL PC Board ass'y BADG-0573-1B 1 1B2565573-1B
N
<MPP>
EV
U0021 D/A & POWER SUPPLY PC Board ass'y BAAR-0574-1C 1 1B2565574-1C
N
<MDC>
EV
U0021 D/A & POWER SUPPLY PC Board ass'y BAAR-0574-1B 1 1B2565574-1B
N
<MPP>
EV
U0022 POWER SWITCH PC Board ass'y BASW-0575-1C 1 1B2565575-1C
N
<MDC>
EV
U0022 POWER SWITCH PC Board ass'y BASW-0575-1B 1 1B2565575-1B
N
<MPP>
EV
U0023 VOLUME PC Board ass'y BAETC-0589-1C 1 1B2565589-1C
N
<MDC>
EV
U0023 VOLUME PC Board ass'y BAETC-0589-1B 1 1B2565589-1B
N
<MPP>
EV
U0024 I/V (Lch) PC Board ass'y BAAF-0593-1C 1 1B2565593-1C
N
<MDC>
EV
U0024 I/V (Lch) PC Board ass'y BAAF-0593-1B 1 1B2565593-1B
N
<MPP>
EV
U0025 I/V (Rch) PC Board ass'y BAAF-0594-1C 1 1B2565594-1C
N
<MDC>
EV
U0025 I/V (Rch) PC Board ass'y BAAF-0594-1B 1 1B2565594-1B
N
<MPP>
EV
<Note>
EV
1. U0024, U0025 and U0021 are connected by soldering.
EV
2. U0024 and U0025 are not included in U0021.
EV
U0030 MUTING PC board ass'y BAETC-1031-1 1 ---
N
NSP
EV
<Note>
EV
U0030 BAETC-1031 has been abolished on the way of mass production. Refer to EXPLODED VIEWS-2 for details.
PV
P-3000R
PV
PACKING PROCEDURES PARTS LIS
T
PV
PV
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PV
[PACKING]
PV
A401 PAD (AS) 1 29092550A <B / S>
PV
A402 SHEET T0.51 x 1100 x 600 1 29096128 <B / S>
PV
A404 TAPE (SEROHAN)NITTO NO.29 1 29110149 <B / S>
PV
A405 PP TAPE W50 SBT-70 1 29110200 <B / S>
PV
A501 CARTON MPP/MDC 1 29055179A
N
<B MDC, MPP / S MPP>
PV
A601A UPC LABEL P-3000(B)MDC { 1} 29391380
N
<B MDC>
PV
A601A EAN LABEL P-3000(S)MPP { 1} 29391384A
N
<S MPP>

Onkyo P-3000R Specifications

General

Output level	0.001 mV
Amplifier class	-
Frequency range	5 - 100000 Hz
Output impedance	330 Ω
Input sensitivity	200 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.005 %
AC (power) in	Yes
Audio (L/R) in	5
USB 2.0 ports quantity	1
Digital audio optical in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	29 W
Package weight	12500 g

Weight and Dimensions

Depth	333.1 mm
Width	435 mm
Height	99 mm
Weight	11000 g
