Onkyo P-3000R Service Manual

53/55 PAGE
U002
R4738 C-CARBON R RN72K1J-331JE 1 435033314R1
U002
R4739 C-CARBON R RN72K1J-152JE 1 435031524R1
U002
R4740 C-CARBON R RN72K1J-152JE 1 435031524R1
U002
R4741 C-CARBON R RN72K1J-331JE 1 435033314R1
U002
R4742 C-CARBON R RN72K1J-331JE 1 435033314R1
U002
R4743 C-CARBON R RN72K1J-223JE 1 435032234R1
U002
R4744 C-CARBON R RN72K1J-223JE 1 435032234R1
U002
R4745 C-CARBON R RN72K1J-821JE 1 435038214R1
U002
R4746 C-CARBON R RN72K1J-821JE 1 435038214R1
U002
R4747 C-CARBON R RN72K1J-272JE 1 435032724R1
U002
R4748 C-CARBON R RN72K1J-272JE 1 435032724R1
U002
R4749 C-CARBON R RN72K1J-101JE 1 435031014R1
U002
R4750 C-CARBON R RN72K1J-101JE 1 435031014R1
U002
R4751 C-CARBON R RN72K1J-100JE 1 435031004R1
U002
R4752 C-CARBON R RN72K1J-100JE 1 435031004R1
U002
R4901 C-CARBON R RN72K2E-047JE 1 435220474R1
U002
R4902 C-CARBON R RN72K2E-047JE 1 435220474R1
U002
R4903 METAL R RNU1/2WCJ-0.22 1 453532294T
U002
R4904 C-CARBON R RN72K2E-047JE 1 435220474R1
U002
R4905 CARBON R R16J-330 1 417343314T
U002
R4906 METAL R RNU1WCJ-0.47 1 453634794T
U002
R4907 METAL R RNU1WCJ-0.47 1 453634794T
U002
R4908 METAL R RNU1WCJ-0.47 1 453634794T
U002
R4909 METAL R RNU1WCJ-0.47 1 453634794T
U002
R4910 CARBON R R16J-330 1 417343314T
U002
R4911 METAL R RNU1/2WCJ-0.22 1 453532294T
U002
R4912 C-CARBON R RN72K2E-047JE 1 435220474R1
U002
R4913 C-CARBON R RN72K2E-047JE 1 435220474R1
U002
R4914 METAL R RNU1/2WCJ-1 1 453530104T <B MPP, B MDC>
U002
R4915 METAL R RNU1/2WCJ-1 1 453530104T <B MPP, B MDC>
U002
R7419 VARI R N16RGL20KB25M 1 5142522 <B MPP, B MDC>
U002
R7431 C-CARBON R RN72K1J-102JE 1 435031024R1 <B MPP, B MDC>
U002
R7443 C-CARBON R RN72K1J-474JE 1 435034744R1 <B MPP, B MDC>
U002
R7452 C-CARBON R RN72K1J-472JE 1 435034724R1 <B MPP, B MDC>
U002
R9301 METAL O R RS1/2WBJ-22 1 443522204T
U002
R9302 METAL O R RS1/2WBJ-330 1 443523314T
U002
R9303 C-CARBON R RN72K1J-331JE 1 435033314R1
U002
R9304 C-CARBON R RN72K1J-331JE 1 435033314R1
U002
R9306 METAL O R RS1/2WBJ-470 1 443524714T

Onkyo P-3000R Specifications

General

Output level	0.001 mV
Amplifier class	-
Frequency range	5 - 100000 Hz
Output impedance	330 Ω
Input sensitivity	200 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.005 %
AC (power) in	Yes
Audio (L/R) in	5
USB 2.0 ports quantity	1
Digital audio optical in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	29 W
Package weight	12500 g

Weight and Dimensions

Depth	333.1 mm
Width	435 mm
Height	99 mm
Weight	11000 g
