Onkyo P-3000R

1/55 PAGE
P-3000R
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
<Notes>
(B) : Black model
(S) : Silver model
<MDC> : 120V,Canadian model
<MPP> : 230V,CE(European) country model
EV
EXPLODED VIEW PARTS LIST
EV
EV
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EV
[CHASSIS SCREW]
EV
A001 BRACKET (F) 1 27131092C
N
<B / S>
EV
A002 SIDE PANEL (L)(S) 1 28185488C <S>
EV
A002 SIDE PANEL (L)(B) 1 28185489C <B>
EV
A003 SIDE PANEL (R)(S) 1 28185486C <S>
EV
A003 SIDE PANEL (R)(B) 1 28185487C <B>
EV
A004 SCREW 3TTB+8B(3BC) 4 838430088GR <B / S>
EV
A005 STAY (BASE) 1 28183008C <B / S>
EV
A006 REAR PANEL MPP 1 27124206C
N
<B MPP / S MPP>
EV
A006 REAR PANEL MDC 1 27124216C
N
<B MDC>
EV
A007 SCREW 3TTB+8B(3BC) 4 838430088GR <B / S>
EV
A008 SCREW 3TTF+10B(3BC) 2 835430108GR <B / S>
EV
A009 CLAMP WS-2NS 2 27300833 <B / S>
EV
A010 BRACKET (TRANS)PRE 1 27131097A
N
<B / S>
EV
A011 SCREW 4TTC+6C(3BC) 6 830440069GR <B / S>
EV
A012 SCREW 3P+6FN(3BC) 1 82143006GR <B / S>
EV
A013 SCREW 3TTB+10B(3BC)TSUME 24 801624GR <B / S>
EV
A014 SCREW 3TTB+8B(3BC) 2 838430088GR <B / S>
EV
A015 BUSHING --- 1 28170070 <B / S>
EV
A016 HOLDER WS-4NS 1 27191207 <B / S>
EV
A017 HOLDER KS CLUMP 1 27191332 <B / S>
EV
A020 STAY (A) 1 28183009 <B / S>
EV
A021 STAY (B) 3 28183010A <B / S>
EV
A025 SCREW 3TTB+8B(3BC) 14 838430088GR <B / S>
EV
A026 SPACER (PC) 2 27270538 <B / S>
EV
A027 SCREW 3P+6FN(3BC) 2 82143006GR <B / S>
EV
A028 SCREW 3TTB+8B(3BC) 2 838430088GR <B / S>
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
