Onkyo P-3000R

5/55 PAGE
PV
A601A EAN LABEL P-3000(B)MPP { 1} 29391385A
N
<B MPP>
PV
A701 SHEET (ACC)A4 1 29096115A <B / S>
PV
[ACCESSARY]
PV
A058 REMO CON RC-797S 1 24140797 <B / S>
PV
A059 BATTERY R03/AAA(UM-4) 2 3010124 <B / S>
PV
A059 or BATTERY R03/24D(UM-4) ( 2) 3010503 <B / S>
PV
A801 WRNTY CARD (ONKYO) 1 29365135 <B MDC>
PV
A803 INST SHEET WEEE 1 29355793A <B MPP / S MPP>
PV
A806 AC CORD AS-CEE-3 1 253298VOL
!
<B MPP / S MPP>
PV
A806 AC CORD AS-UC-2 1 253301VOL
!
<B MDC>
PV
A856 INS MANUAL En(P-3000) 1 29400534
N
<B MDC, MPP / S MPP>
PV
A857 INS MANUAL U2FrEs(P-3000) 1 29400535
N
<B MDC, MPP / S MPP>
PV
A858 INS MANUAL U2ItDe(P-3000) 1 29400536
N
<B MPP / S MPP>
PV
A859 INS MANUAL U2NiSv(P-3000) 1 29400537
N
<B MPP / S MPP>
PV
A863 INS MANUAL U9(P-3000R) 1 29400616
PV
A901 POLY BAG w250 x d350 1 29100250A <B / S>
PV
A902 TAPE (SEROHAN)NITTO NO.29 1 29110149 <B / S>
P-3000R
U001
PC BOARD PARTS LIS
T
U001
U001
U001 U0010 + U0011 + U0012 + U0013 + U0014 + U0015 + U0016 + U0017 + U0018
U001
U0010
AUDIO PC Board BAASP-0568-1B
U001
U0011
DISPLAY PC Board BADIS-0567-1B
U001
U0012
HEADPHONE AMP. PC Board BAAF-0569-1B
U001
U0013
PHONO EQ. AMP. (Lch) PC Board BAAF-0570-1B
U001
U0014
PHONO EQ. AMP. (Rch) PC Board BAAF-0571-1B
U001
U0015
HEADPHONE JACK PC Board BATRM-0572-1B
U001
U0016
STANDBY SWITCH PC Board BASW-0586-1B
U001
U0017
INPUT SELECTOR PC Board BAETC-0590-1B
U001
U0018
TONE CONTROL PC Board BAAF-0599-1B
U001
U001
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
U001
[SEMI CONDUCTOR]
U001
D101 ZENER D UDZS5.1B 1 224550510R2
U001
D102 ZENER D UDZS5.1B 1 224550510R2
U001
D103 ZENER D UDZS5.1B 1 224550510R2
U001
D104 ZENER D UDZS5.1B 1 224550510R2
U001
D105 C-DIODE 1SS352 1 223234R2
