Onkyo P-3000R Service Manual

54/55 PAGE
U002
R9307 C-CARBON R RN72K1J-273JE 1 435032734R1 <B MDC>
U002
R9307 C-CARBON R RN72K1J-473JE 1 435034734R1 <B MPP>
U002
R9308 C-CARBON R RN72K1J-473JE 1 435034734R1
U002
R9309 C-CARBON R RN72K1J-103JE 1 435031034R1
U002
R9310 C-CARBON R RN72K1J-223JE 1 435032234R1
U002
[SW TRM]
U002
E001 TRM-423(SCREW) NEJITANSI ST3 1 25060495
U002
P1006A PLUG IDC 2.54-26P(S) 1 25056678
U002
P1007 SOCKET IMSA-9117S-13D 1 25053401 N
U002
P1008 SOCKET IMSA-9618S-09A 1 25053334R2
U002
P1009 SOCKET NSCT-4P2179 1 25052282
U002
P1010 SOCKET AS NSAS-30P1922 1 200C4293010UL N <B MPP, B MDC>
U002
P1011 SOCKET AC3FAH2-AU-B 1 25053400 N
U002
P1013 PIN JACK NPJ-1PDB708 1 25045942
U002
P1014 PIN JACK NPJ-1PDB708 1 25045942
U002
P1015A PLUG NPLG-7P135 1 25055151
U002
P1015B SOCKET AS NSAS-14P1910 1 200C4291410UL N
U002
P1016 PHT CP JSR1165-001recieving 1 24120143
U002
P1017 PLUG NPLG-9P123 1 25055139
U002
P1018 PHT CP JSR1165-001recieving 1 24120143
U002
P1019 PHT CP JST1165-001transmitting 1 24120142
U002
P1020 ST JACK MSJ-035-52E-B-AG-PBT 1 25045947
U002
P4005 SOCKET AS NSAS-10P1930 1 200B3090525UL N <B MPP, B MDC>
U002
P4201D PLUG IMSA-9210B-1-13ZA075-PT1 1 25056675
U002
P4500A PLUG MB7P-90 1 25056629
U002
P4600A PLUG MB7P-90 1 25056629
U002
P4901 PLUG NPLG-4P151 1 25055167
U002
P7403B PLUG NPLG-5P133 1 25055149 <B MPP, B MDC>
U002
P902A CRIMP AS CRIMP_P3000R 1 20799187UL N <B MPP, B MDC>
U002
P903A CRIMP AS CRIMP_PAMC5500 1 20799180UL <B MPP, B MDC>
U002
P9301 PLUG NPLG-2P632 1 25055676 <B MPP, B MDC>
U002
P9303 PLUG NPLG-2P632 1 25055676
U002
P9304A SOCKET AS NSAS-4P1003 1 2009990716UL
U002
P9304C PLUG NPLG-2P632 1 25055676
U002
P9305 PLUG NPLG-2P632 1 25055676 <B MPP, B MDC>
U002
RL9301 RELAY NRL-1P5A-DC9-179 1 25065669
U002
S9501 P SW NPS-111-L687P(TV-5) 1 25035724
U002
[MECHA PARTS]
U002
A501 CUSHION ---t10*10*15 1 28141614-1 <B MPP, B MDC>

Onkyo P-3000R Specifications

General

Output level	0.001 mV
Amplifier class	-
Frequency range	5 - 100000 Hz
Output impedance	330 Ω
Input sensitivity	200 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.005 %
AC (power) in	Yes
Audio (L/R) in	5
USB 2.0 ports quantity	1
Digital audio optical in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	29 W
Package weight	12500 g

Weight and Dimensions

Depth	333.1 mm
Width	435 mm
Height	99 mm
Weight	11000 g
